USB Port Pin-out (Face-In)

Pin1: External Power Supply (+5 VDC)
Pin2: Logger Communications Receiver Line (RX)
Pin3: Logger Communications Transmitter Line (TX)
Pin4: Common Ground (COM , GND)
3
.
C
h
a
n
n
e
l
s
3
.
C
h
a
n
n
e
l
s
Most of iLog data loggers have one on-board thermistor located beside the status LED.
All "COM" terminals are connected together and should be connected to the common ground of
the process signals.

iLog Voltage Data Logger, Model: iVDC-10

Besides the on-board thermistor channel, the logger has one external voltage DC channel used
to measure single-ended voltage DC signal maximum of 10 volt. The following figure
illustrates the correct input connections:
Note: All inputs must share the same common ground.
iLog Data Loggers User's Manual
1
a
n
d
S
e
n
s
o
r
c
a
n
d
S
e
n
s
o
r
c
Voltage External Input Connections
2
3
4
5
o
n
n
e
c
t
i
o
n
s
o
n
n
e
c
t
i
o
n
s
Page 11/63
