11/01 Rev. 2.13-01
Servicing and Maintenance
General Notes ............................................... 2
Servicing by trained personnel................... 2
Safety ........................................................ 2
Fault correction.......................................... 2
Ordering spare parts.................................. 3
Servicing and cleaning .................................. 4
Notes for cleaning...................................... 4
Cleaning the print head.............................. 5
Changing the print head ............................ 6
USER MANUAL
TTX 350 - Ocelot
Cleaning the print roller.............................. 7
version....................................................... 8
photoelectric switch ................................... 9
Cleaning the rollers and shafts................... 9
Cleaning the cutter..................................... 9
Index ........................................................... 10
Servicing and Maintenance, Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TTX 350 Ocelot and is the answer not in the manual?

Questions and answers

Related Manuals for Novexx Solutions TTX 350 Ocelot

Summary of Contents for Novexx Solutions TTX 350 Ocelot

  • Page 1: Table Of Contents

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 1 TTX 350 - Ocelot Servicing and Maintenance General Notes ..........2 Cleaning the print roller......7 Servicing by trained personnel....2 Cleaning the print roller / dispenser version............8 Safety ............2 Cleaning the gap/material end Fault correction..........

  • Page 2: General Notes

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 2 TTX 350 - Ocelot General Notes Servicing by trained personnel Regular and proper servicing is necessary in order to ensure that the device is permanently ready for operation. Qualification Servicing and repair work may only be carried out by appropriately qualified personnel.

  • Page 3: Ordering Spare Parts

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 3 TTX 350 - Ocelot Ordering spare parts Only use original spare parts from the manufacturer. The use of parts which do not satisfy the high demands set by the printer manufacturer can cause unnecessary problems.

  • Page 4: Servicing And Cleaning

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 4 TTX 350 - Ocelot Servicing and cleaning Notes for cleaning Regular servicing and cleaning work is necessary for safe operation and Intervals high running performance. The servicing intervals are dependent on the operation and ambient conditions, daily operating times and the print medium.

  • Page 5: Cleaning The Print Head

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 5 TTX 350 - Ocelot Cleaning the print head 1. Switch off the device. 2. Pull out the mains plug. 3. Remove material and ribbon. 4. Unscrew both thumb screws (1) on the print head.

  • Page 6: Changing The Print Head

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 6 TTX 350 - Ocelot Changing the print head 1. Switch off the device. 2. Pull out the mains plug. 3. Remove material and ribbon. 4. Pull out both of the plugs from the print head. Wait at least 3 minutes after switching off the device before removing the print head cable from the print head.

  • Page 7: Cleaning The Print Roller

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 7 TTX 350 - Ocelot Cleaning the print roller 1. Switching off the device. 2. Pull out the mains plug. 3. Remove material and ribbon. 4. Loosen the thumb screw (1) in the centre of the tear-off edge (2).

  • Page 8: Cleaning The Print Roller / Dispenser Version

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 8 TTX 350 - Ocelot Cleaning the print roller / dispenser version 1. Switch off the device. 2. Pull out the mains plug. 3. Remove material and ribbon. 4. Remove the dispenser sensor (1). To do this, loosen both the Allan key screws (2) on the sensor.

  • Page 9: Cleaning The Gap/Material End Photoelectric Switch

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 9 TTX 350 - Ocelot Cleaning the gap/material end photoelectric switch 1. Switch off the device. 2. Pull out the mains plug. 3. Remove the material. 5. Use compressed air to remove dust and material residue from the gap photoelectric switch (compressed air can be ordered in a can as an accessory).

  • Page 10: Index

    11/01 Rev. 2.13-01 USER MANUAL Servicing and Maintenance, Page 10 TTX 350 - Ocelot Index Bottom cutter ..........9 HRES ............6 Charges, electrostatic......5, 6 Ink residue ..........6 Cleaning ............. 4 Ink residues ..........4 Cleaning agents ......... 4 Cleaning fuel ..........4 Knives.............7, 8 Cleaning print roller, dispenser version..
