12/00 Rev. 2.13-01
SERVICE MANUAL
Fault location, Page 1
-
-
TTX x50/67x
Wildcats (plus)
S 45/65/95/105
Fault location
General information about fault location ........ 2
Data transfer ................................................. 2
Display .......................................................... 2
Punch recognition ......................................... 3
Material transport TTX 350............................ 4
Ribbon, ribbon guide ..................................... 5
Feed rollers ................................................... 6
Position of printed image............................... 7
Print quality ................................................... 8
Cutting function, cutter .................................. 9
Transport unit.............................................. 10
Plug-in cards ............................................... 10
Index ........................................................... 11
Advertisement
Table of Contents
Related Manuals for Novexx Solutions TTX 50 Series
Summary of Contents for Novexx Solutions TTX 50 Series
-
Page 1: Table Of Contents
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 1 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Fault location General information about fault location ..2 Data transfer ..........2 Display ............2 Punch recognition ......... 3 Material transport TTX (without TTX 350)..3 Material transport TTX 350...... -
Page 2: General Information About Fault Location
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 2 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 General information about fault location In order to check the mechanical and electronic operability, the status reports STA0 to STA3 should be printed out and evaluated – assuming no obvious defects are present. -
Page 3: Punch Recognition
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 3 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Punch recognition Symptom Possible cause Solution Status message Position of light barrier not Correct the position of the light barrier ST05 although sufficiently accurate material is inserted Punch recognition not Light barrier defective... -
Page 4: Material Transport Ttx 350
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 4 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Material transport TTX 350 Symptom Possible cause Solution No feed function Stepping motor plug loose Check and insert if necessary Stepping motor defective Check and replace if necessary Mainboard defective Check and replace if necessary... -
Page 5: Ribbon, Ribbon Guide
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 5 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Ribbon, ribbon guide Symptom Possible cause Solution Unfounded end-of- Ribbon unwinder mandrel Affix core to mandrel (spring leaf). Slide ribbon message is not turning spring leaf if the thread is torn out. -
Page 6: Feed Rollers
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 6 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Feed rollers TTX 350 has only one feed roller Symptom Possible cause Solution Wear / abrasion High output / performance Replace roller (not TTX 350) Check and correct if necessary contact pressure of the thermal strip too high... -
Page 7: Position Of Printed Image
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 7 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Position of printed image Symptom Possible cause Solution Print position Incorrect parameter setting Check PRTP/YPOS parameters or Easy displaced in or Plug command and correct if necessary opposite to the direction of printing Punch position is... -
Page 8: Print Quality
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 8 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Print quality Symptom Possible cause Solution Printing weak Thermal strip dirty or Clean or replace thermal strip defective Thermal-strip setting Check settings (e.g. HVxx) and adjust if incorrect necessary Incorrect print-head... -
Page 9: Cutting Function, Cutter
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 9 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Cutting function, cutter Symptom Possible cause Solution No cutter function Plug connections loose Check and correct if necessary Cutter function not Select and activate KNIF in the parameter activated menu Cutter board is missing... -
Page 10: Transport Unit
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 10 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Transport unit Symptom Possible cause Solution No material transport (not TTX 350) Check and set if necessary incorrect setting of the pressure rollers Driving belt defective Check and replace if necessary Stepping motor defective... -
Page 11: Index
12/00 Rev. 2.13-01 SERVICE MANUAL Fault location, Page 11 – – TTX x50/67x Wildcats (plus) S 45/65/95/105 Index Cutting function, cutter, Troubleshooting Plug-in cards, Troubleshooting Print quality, Troubleshooting Punch recognition, Troubleshooting Data transfer, troubleshooting Display, troubleshooting Ribbon/ribbon guide, Troubleshooting Feed rollers, Troubleshooting Transport unit, Troubleshooting Material transport, Troubleshooting 3, 4...
