Novexx Solutions AP 3.4 User Manual

Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

07/02 Rev. 2.16-00
Setup
Loading the Ribbon ....................................... 2
Loading the Media ........................................ 4
Standard Mode .......................................... 4
Peel Off Mode ........................................... 6
Cutter Mode .............................................. 7
Performing Calibration .............................. 8
Index ............................................................. 9
USER MANUAL
AP 3.4
Seite / Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP 3.4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Novexx Solutions AP 3.4

Summary of Contents for Novexx Solutions AP 3.4

  • Page 1: Table Of Contents

    07/02 Rev. 2.16-00 USER MANUAL Seite / Page 1 AP 3.4 Setup Loading the Ribbon ........2 Loading the Media ........4 Standard Mode .......... 4 Peel Off Mode ........... 6 Cutter Mode ..........7 Performing Calibration ......8 Index ............. 9...

  • Page 2: Loading The Ribbon

    07/02 Rev. 2.16-00 USER MANUAL Setup, page 2 AP 3.4 Loading the Ribbon Œ « This section is not applicable to the direct thermal printing. « R-series ribbons are wound face (inside coating). « Optional ribbon core adapter is available once ribbon width is less than 4’’...
  • Page 3 07/02 Rev. 2.16-00 USER MANUAL Setup, page 3 AP 3.4 7. Turn back the print head module and then insert the bare core into the pick-up holder. To do so, first snap in the right side, then the left side (Fig. 1).

  • Page 4: Loading The Media

    USER MANUAL Setup, page 4 AP 3.4 Loading the Media Œ AP 3.4 printers can be operated in three diffe- rent options: standard, peel-off, or with a cutter. • Standard mode allows you to collect each label freely. H See paragraph Standard Mode page 4.
  • Page 5 07/02 Rev. 2.16-00 USER MANUAL Setup, page 5 AP 3.4 6. Lead the media over the platen roller (Fig. 1). 7. Turn back the print head module and then press it down firmly on both sides till you hear a snap (Fig. 2).

  • Page 6: Peel Off Mode

    07/02 Rev. 2.16-00 USER MANUAL Setup, page 6 AP 3.4 Peel Off Mode H For installing the dispenser kit, please re- fer to the Service Manual. 1. Follow the common procedure of "Loa- ding the Media" as described in Stan- dard Mode.

  • Page 7: Cutter Mode

    07/02 Rev. 2.16-00 USER MANUAL Setup, page 7 AP 3.4 8. Turn on the printer and press FEED but- ton. 9. Labels will be separated from backing paper and fed out on H cover, while backing paper will come out from the slot under the H cover, and label will be fed out.

  • Page 8: Performing Calibration

    07/02 Rev. 2.16-00 USER MANUAL Setup, page 8 AP 3.4 Performing Calibration After the media loaded, it is necessary to do the calibration for the label size detection. 1. Press and hold the PAUSE button. 2. Turn on the power.

  • Page 9: Index

    07/02 Rev. 2.16-00 USER MANUAL Setup, page 9 AP 3.4 Index Backing paper Peel Off Mode Calibration Ribbon core adapter Cutter Mode Ribbon loading Media loading Standard Mode...
