03/13 Rev. 5.08-01
Maintenance & Cleaning
General Notice .............................................. 2
Safety . ....................................................... 2
Troubleshooting ...... .................................. 2
Ordering Spare Parts ................................ 3
Note on Cleaning ...................................... 3
Cleaning Agents ........................................ 3
Printhead ....................................................... 5
General Notes ........................................... 5
Cleaning the printhead .............................. 6
Changing the print head ............................ 8
Checking the print head ............................ 9
Rubber rollers ............................................. 11
Feed / Print roller ..................................... 11
(PEM) Pressure roller .............................. 12
USER MANUAL
DPM - PEM - ALX 92x
Deflection rollers ..........................................13
roller .........................................................13
Photoelectric switches .................................14
switch .......................................................16
Cleaning the foil path ...................................17
Replacing the dust filter liner .......................18
DPM/PEM ...... ..........................................18
ALX ..... .....................................................19
