- Page 1 MAGPOWR DFC-90 Instruction Manual Dancer-Follower Arm Control 90VDC MI 850A265 1 G...
-
Page 2: Table Of Contents
Sensor setup ......................5-2 Dancer control setup and tuning ................5-3 Optional dancer optimization ................5-5 TROUBLESHOOTING Follower arm applications ..................6-1 Dancer applications ....................6-2 SPECIFICATIONS SERVICE Maintenance ......................7-1 Replacement parts ....................7-1 www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 3: Introduction
All of the information herein is the exclusive proprietary property of Maxcess International, and is disclosed with the understanding that it will be retained in confidence and will neither be duplicated nor copied in whole or in part nor be used for any purpose other than for which disclosed. -
Page 4: Product Overview
Modifying this setting will cause the clutch/brake drag torque to be higher than expected and is not recommended. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 5: Installation
SHIELD. Maximum shield length and maximum length of wires outside of the shield is 75 mm [3.0 inches]. 2.30 [58.4mm] 6.18 [157.0mm] 1.39 [35.2mm] 3.38 [85.9mm] Figure 1. Enclosure dimensions www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 6: Setup
DFC-90 (See Figure 3 for current range settings). The factory setting is 1/8 A range. 3. Replace the enclosure top. Figure 2. Enclosure top removal Figure 3. JP1 current settings www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 7: Follower Arm Applications
(See Figure 4.) FULL ROLL DIAMETER CORE DIAMETER Figure 4. Follower arm setup (continued) www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 8: Control Setup
The control adjustments marked with an underline on the label are the only ones needed for follower arm adjustment Stop Time and Stop Multiplier apply to all operating modes and are not distinctively marked. (See Figure 6 and settings on next page.) www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... - Page 9 7. Place the follower arm at the full roll position, and adjust the FULL pot to the desired output current at full roll. Setup is complete, and the DFC-90 is ready for operation. (continued) www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G...
-
Page 10: Operation
Rotate the STOP MULT pot clockwise to increase the stopping torque. Rotate the STOP TIME pot clockwise to increase the time that the stopping torque is applied. The STOP TIME may be adjusted from 0.2 to 60 seconds. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 11: Dancer Applications
ALLOWED IN D.C. OUTPUT CLUTCH/ BRAKE REMOTE RUN/STOP INCREASING METER OPEN FOR RUN LOAD CURRENT 0-1 madc (OPTIONAL FOR PD) (OPTIONAL) (REQUIRED FOR PID) (REQUIRED FOR STOP MULTIPLIER) Figure 7. Dancer electrical connections www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 12: Sensor Setup
(wiper), to the red or black wire. Turn the potentiometer shaft until the meter reads 500Ω. Install the DFP-2 sensor so that at the 500Ω meter reading, the dancer is halfway through its travel. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 13: Dancer Control Setup And Tuning
D to minimize oscillations is system dependent. 4. If dancer arm oscillations cannot be eliminated, turn the P pot counter-clockwise and repeat step 3. Calibration is complete, and the DFC-90 is ready for operation. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... - Page 14 (terminals 17 and 18). The length of time the increased torque is applied is adjusted by the STOP TIME pot. Using the stop multiplier feature in dancer mode could cause the dancer to oscillate while the machine is stopping. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G...
-
Page 15: Optional Dancer Optimization
4. Increase the P pot by rotating clockwise in small steps checking for dancer overshoot at each step. Do this until overshoot is obtained. (continued) www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... - Page 16 Do this until overshoot is obtained. 4. Increase the pot by the amount necessary to eliminate the overshoot. Adjustment is now complete for the dancer operating in PID mode. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G...
-
Page 17: Troubleshooting
Meter should be a current meter with 1 mA working full scale and no more than 3kΩ resistance. Meter wires shorted or open Disconnect meter wiring at the DFC-90 and check for proper meter resistance between the wires. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 18: Dancer Applications
Meter should be a current meter with working 1 mA full scale and no more than 3kΩ resistance. Meter wires shorted or open Disconnect meter wiring at the DFC-90 and check for proper meter resistance between the wires. www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 19: Specifications
-0.016 to 0.5 ADC -0.032 to 1.0 ADC Regulation: < 1% of range Meter signal 0 to 1 mADC, +/-2% into 3kΩ maximum DFP or DFP-2 10 V +/-2%, 10 mADC maximum reference voltage www.maxcessintl.com MAGPOWR DFC-90 MI 850A265 1 G... -
Page 20: Service
AND AFRICA AND SE ASIA Tel +1.405.755.1600 Tel +86.756.881.9398 Tel +91.22.27602633 Tel +81.43.421.1622 Tel +49.6195.7002.0 asia@maxcessintl.com Fax +1.405.755.8425 Fax +86.756.881.9393 Fax +91.22.27602634 Fax +81.43.421.2895 Fax +49.6195.7002.933 www.maxcess.asia sales@maxcessintl.com info@maxcessintl.com.cn india@maxcessintl.com japan@maxcessintl.com sales@maxcess.eu www.maxcessintl.com www.maxcessintl.com.cn www.maxcess.in www.maxcess.jp www.maxcess.eu © 2018 Maxcess...
