Summary of Contents for HOMCOM 821-020V80

  • Page 2: Before You Begin

    1. BEFORE YOU BEGIN Please read the operating instructions carefully before using your dehumidifier for the first time. 1.1 PRODUCT DESCRIPTION The dehumidifier is used to remove excessive moisture from the air. The resulting reduction in relative humidity protects buildings and their contents from the adverse effects of excess humidity.
  • Page 3 ⚫ Do not unplug by pulling on the power cord. ⚫ Do not use an extension cord or an adapter plug. ⚫ Do not put objects on the unit. ⚫ Do not climb or sit on the unit. ⚫ Do not insert fingers or other objects into the air outlet. ⚫...
  • Page 4 Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the person competent in the use of flammable refrigerants. If you don't understand something or need help, please contact the dealer services SAFETY PRECAUTIONS ON SERVICING Please follow these warnings when to undertake the following when servicing a dehumidifier with R290.
  • Page 5 No person carrying out work in relation to a refrigeration system which involves exposing any pipe work that contains or has contained flammable refrigerant shall use any sources of ignition in such a manner that it may lead to the risk of fire or explosion. All possible ignition sources, including cigarette smoking, should be kept sufficiently far away from the site of installation, repairing, removing and disposal, during which flammable refrigerant can possibly be released to the surrounding space.

  • Page 6: Product Overview

    electrical supply shall be connected to the circuit until it is satisfactorily dealt with. If the fault cannot be corrected immediately but it is necessary to continue operation, an adequate temporary solution shall be used. This shall be reported to the owner of the equipment so all parties are advised.

  • Page 7: Installation

    Top panel Handle Air Filter Back Shell Continuous drainage 口 Water tank FEATURES ✓ Powerful moisture removal ✓ Humidity Monitor shows current air humidity ✓ Auto mode automatically adjusts humidity levels ✓ A 24-hour timer to set the time of operation ✓...
  • Page 8 proper air circulation. 2.Never install the unit where it could be subject to ： ⚫ Quellen Heat sources such as radiators, heating registers, stoves or other products that generate heat. ⚫ In an area where oil or water can be splashed ⚫...

  • Page 9: Operation

    ⚫ It is normal for air outlet to feel warm to touch after continuous operation on hot days. ⚫ Empty the water tank before moving the device. ⚫ Make sure the Water tank is correctly fitted otherwise the unit will not operate properly. ⚫...
  • Page 10 immediately, and then the fan shut down after 30 seconds delay. Mode Auto mode - continuously drying mode-sleeping mode cycle, press once to switch the mode from one to another, the corresponding indicator lights up. ● Auto mode: when environmental humidity ≥ set humidity +3%, the fan starts working and compressor starts working after 3 seconds.
  • Page 11 Humidity adjusting the order of 30% to 80% - 75% - 70% - 65% - 60% - 55% - 50% - 45% - 40% - 35% - 30%; Time set to 00, press this key, display 00 and blink, and then press this key again every time, from 24-23-22-..
  • Page 12 1、 Pull out the water tank 2、 Empty the water tank 3、 Replace the empty tank back into the unit III.Warning! 1、 Do not discard the magnets and plastic rivets in the tank. Otherwise, the dehumidifier cannot be started, or the machine will not automatically stop working when the water tank is full, and the condensed water overflow will damage the floor of the room.

  • Page 13: Maintenance

    and cause leaks 4、 Put the water tank in its original position. Otherwise, the indicator light will always be red and the machine cannot start working again Continuous drainage 1、 Take out the PVC pipe, Straighten the drain pipe 2、 Insert one end of the drain pipe into the drain outlet at the top of the tank and connect the other end to the bathroom, floor drain, outdoor or bucket like container, defined drain area Drain pipe...
  • Page 14 efficiency of the system and if it becomes blocked it can cause damage to the unit. The air filter requires regular cleaning. The air filter is removable for easy cleaning. Do not operate the unit without an air filter, or the evaporator may be contaminated. ；...

  • Page 15: Troubleshooting

    TROUBLESHOOTING SYMPTOM INSPECTION SOLUTION ✓ Check the power ➢ Insert the power cord securely into the connection in securely. wall Outlet. The unit is not ✓ Check if the water level ➢ Empty the water tank and reinstall correctly. operating. indicator lights up? ✓...
