- Page 1 All manuals and user guides at all-guides.com XM-7603 FLAT INCLINE BENCH Owner’s Manual 8/09...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com Table of Contents Important Safety Information Before You Start Assembly Parts List Exploded View Warranty Information... -
Page 3: Important Safety Information
SAFETY PRECAUTIONS • This unit should only be used on a level surface and is intended for indoor use only. XMARK Fitness recommends an equipment mat be placed under the unit to protect the floor or carpet and for easier cleaning. -
Page 4: Before You Start
This manual will guide you through the assembly process. If at any time you are having trouble with the assembly or use of this product, then please contact us at our XMARK Fitness help line. We have trained service technicians on site to take care of you, our valued customer. -
Page 5: Assembly
All manuals and user guides at all-guides.com Assembly... - Page 6 All manuals and user guides at all-guides.com Assembly NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled. Step 1 Attach Main Frame (#1) to U-Shaped Base (#3) using: • two M12*80 Button Head Cap Screw (#28) •...
- Page 7 All manuals and user guides at all-guides.com Assembly NOTE: Hand tighten bolts and Nylon Lock nuts until machine is fully assembled. Step 2 Attach Seat Pad (#8) to Seat Support (#4) using: • two Φ11*Φ20*1.5 Flat Washer (#31) • two M10*70 Button Head Cap Screw (#26) Attach Seat Support (#4) to Main Frame (#1) using: •...
- Page 8 All manuals and user guides at all-guides.com Assembly NOTE: Wrench Tighten bolts and Nylon Lock Nuts. Step 3 Attach Back Pad Support (#5) to Main Frame (#1) using: • one Shaft Bolt (#23) • two Φ13*Φ26*2 Flat Washer (#32) • two M12 Nylon Lock Nut (#34) Attach Support Frame, ADJ.
-
Page 9: Parts List
Seat Support P00043 Back Pad Support P00410 Support Frame, ADJ. Slide Frame P00243 P00044 Seat Pad, XM-7603 P00045 Back Pad, Upper XM-7603 P00414 Iron Bushing, 21.8*12.2*8 P00573 P00415 Spring P00153 Foot Cap, Right 50.8 XM Series Plastic Sleeve 50.8*44.5 P00416... -
Page 10: Exploded View
All manuals and user guides at all-guides.com Exploded View... -
Page 11: Warranty Information
All manuals and user guides at all-guides.com XMARK Fitness 7501 Trammel Drive Shreveport, LA 71108 Customer Service: 1-800-719-4605...
