- Page 1 Version 1.7 OXY5362A 3.5" SBC with Intel® Kabylake-U SoC www.perfectron.com...
-
Page 2: Safety Information
All rights reserved. No part of this publication may be reproduced in any form or by any means, without prior written permission from the publisher. All trademarks are the properties of the respective owners. All product specifications are subject to change without prior notice. www.perfectron.com... -
Page 3: Revision History
Modify Half size mPCIe slot only support mSATA V 1.6 22.11.2021 Add COM1 pin define V 1.7 10.02.2022 Add AMP1 pin define Packing list OXY5362A 3.5” SBC □ CD (Driver + user's manual) □ Optional Accessories □ Cable kit •... -
Page 4: Table Of Contents
........................... 15 4.1 Starting ................................15 4.2 Navigation Keys ............................. 15 4.3 Main Menu ................................ 16 4.4 Advanced Menu .............................. 17 4.5 Chipset ................................23 4.6 Security ................................26 4.7 Boot Menu ................................ 27 4.8 Save & Exit ............................... 28 www.perfectron.com... -
Page 5: Chapter 1: Product Information
Chapter 1: Product Information 1.1 Block Diagram SATA www.perfectron.com... -
Page 6: Key Features
Operating Temp. -40 to 85°C Storage Temp -40 to 85°C Relative Humidity 10% to 90%, non-condensing Standard Compliance Standard Compliance CE/FCC ® Support Windows 10 64-bit , Linux(Support by request) *All specifications and photos are subject to change without notice. www.perfectron.com... -
Page 7: Board Placement
1.3 Board Placement CN11 www.perfectron.com... -
Page 8: Chapter 2: Jumpers And Connectors
ATX Power DIO header SATAIII connector SATA power Front panel LPC header Audio COM2, RS232/422/485 CPU fan 2 x USB2.0, USB5/6 LVDS resolution Select Clear CMOS COM1 RI/+5V/+12V select JP13 AT/ATX select JP14 mPCIE1 SATA/PCIe select JP15 mPCIE2 SATA/PCIe select www.perfectron.com... -
Page 9: Connector And Jumper Pin Definition
JP1: Clear CMOS Jumper Function description Setting Normal Clear CMOS Default setting: 1-2 JP2: COM1 RI/+5V/+12V Jumper Function description Setting Ring Default setting: 1-2 JP13: AT/ATX Mode Jumper Function Setting Default setting: 2-3 JP14: mPCIe1 signal select Jumper Function Setting SATA www.perfectron.com... - Page 10 800 x 600 18-bit Single 1024 x 768 18-bit Single 1024 x 768 24-bit Single 1280 x 800 18-bit Single 1280 x 1024 24-bit Dual 1366 x 768 24-bit Single 1440 x 900 24-bit Dual 1920 x 1080 24-bit Dual www.perfectron.com...
- Page 11 LVDSA3+ LVDSA3- LVDSB3+ LVDSB3- LVDSA_CLK+ LVDSB2+ LVDSA_CLK- LVDSB2- LVDSB1+ LVDSA2+ LVDSB1- LVDSA2- LVDSB0+ LVDSA1+ LVDSB0- LVDSA1- LVDSA0+ LVDS_SCLK LVDSA0- LVDS_SDATA 28 CN11: ATX Power PIN DEFINITION DC in DC in CN18: LVDS Control connector PIN DEFINITION +12V +12V +12V www.perfectron.com...
- Page 12 3 GND 4 5V J9: Front Panel PIN DEFINITION PIN DEFINITION 1 FP_HDLED+ 2 FP_PLED+ 3 SATALED# 4 GND 5 GND 6 EC_PWR_BTN 7 RESET- 8 GND J10: LPC PIN DEFINITION +3.3VSB LPC_AD0 LPC_AD1 LPC_AD2 LPC_AD3 LPC_FRAME# PLTRST#_BUF1 10 LPC_CLK_1 www.perfectron.com...
- Page 13 J11: Audio PIN DEFINITION MIC1_JD MIC1_R MIC1_L FRONT_JD FRONT_R FRONT_L LINE1_JD LINE1_R 10 LINE1_L COM1: RS232 with 5V/12V selectable J12: COM2 RS232/422/485 Note: RS232/422/485 can be set by BIOS. RS232 mode (Default) RS422 mode RS485 mode DATA- DATA+ www.perfectron.com...
- Page 14 J14: USB2.0 x 2 PIN DEFINITION USB5- USB5+ USB6- USB6+ 10 GND www.perfectron.com...
-
Page 15: Chapter 3: Quick Installation Guide
Chapter 3: Quick Installation Guide www.perfectron.com... -
Page 16: Chapter 4: Ami Bios Utility
The <F4> key saves any changes made and exits the BIOS setup utility. The <Esc> key discards any changes made and exits the BIOS setup utility. The <Enter> key displays a sub-screen or changes a selected or highlighted Enter option in each menu. www.perfectron.com... -
Page 17: Main Menu
4.3 Main Menu The Main menu is the first screen that you will see when you enter the BIOS Setup Utility. www.perfectron.com... -
Page 18: Advanced Menu
Setting incorrect field values may cause the system to malfunction. 4.4.1 Trust Computing www.perfectron.com... - Page 19 4.4.2 IT8786 Super IO Configuration 4.4.2.1 Serial Port 1 Configuration www.perfectron.com...
- Page 20 4.4.2.2 Serial Port 2 Configuration www.perfectron.com...
- Page 21 4.4.3 Hardware Monitor 4.4.4 CPU Configuration www.perfectron.com...
- Page 22 4.4.5 SATA Configuration www.perfectron.com...
- Page 23 4.4.6 CMS Configuration 4.4.7 USB Configuration www.perfectron.com...
-
Page 24: Chipset
4.5 Chipset 4.5.1 System Agent (SA) Configuration www.perfectron.com... - Page 25 4.5.1.1 Graphic Configuration 4.5.1.1.1 LCD Control www.perfectron.com...
- Page 26 4.5.1.2 Memory Configuration 4.5.2 PCH-IO Configuration www.perfectron.com...
-
Page 27: Security
4.6 Security Administrator Password www.perfectron.com... -
Page 28: Boot Menu
Set administrator password. User Password Set user Password. 4.7 Boot Menu This section is used to configure the boot features. www.perfectron.com... -
Page 29: Save & Exit
4.8 Save & Exit www.perfectron.com...
