  • Page 1 Version 1.1 OXY5740A Intel® QM175 EBX SBC, Kaby Lake i7-7820EQ (4C x 3.7/3.0 GHz), 8M Cache, with SSD Soldering onboard,Stackable with Stack PC & FPE Expansio www.perfectron.com...

  • Page 2: Safety Information

    OXY5740A EBX SBC User’s Manual V1.1 Safety Information Electrical safety  To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.  When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected.

  • Page 3: Revision History

    CD(Drivier + User’s manual) Optional Accessories • 1 x terminal block • [Optional] Cable kit for OXY5740A: 1 x SATA, 1 x SATA power, 1 x COM If any of the above items is damaged or missing, please contact your local distributor. www.perfectron.com...

  • Page 4: Table Of Contents

    OXY5740A EBX SBC User’s Manual V1.1 Table of Contents Safety Information ............................1 Electrical safety ............................1 Operation safety .............................1 Statement ..............................1 Revision History ............................2 Packing list ..............................2 Chapter 1: Product Information ......................5 1.1 Specifications ............................5 1.2 Block Diagram ...........................7 1.3 Board Placement ..........................8...
  • Page 5 OXY5740A EBX SBC User’s Manual V1.1 4.6 Security ………………………………… ................4.7 Boot …………………………………………………… ............4.8 Save & Exit ………… ...................... www.perfectron.com...

  • Page 6: Chapter 1: Product Information

    OXY5740A EBX SBC User’s Manual V1.1 Chapter 1 : Product Introduction 1.1 Specifications System Intel® Kaby Lake-H Core™ Processor Intel® Core™ i7-7820QE Processor (4 Cores/8 Threads, 8M Cache,up to 3.70GHz), 45W Chipset Intel® QM175 Memory type 1 x SO-DIMM up to 32GB...
  • Page 7 OXY5740A EBX SBC User’s Manual V1.1 Internal I/O SATAIII 2(0,1 RAID) 3 x RS-232 (1 with 5V/12V Selectable) USB 2.0 SIM card holder 8bit, 6-in / 2-out LVDS Mechanical and Environmental Form Factor Power Type DC-IN 12V Dimension 203mm x 146mm Operation -40 to 85°C...

  • Page 8: Block Diagram

    OXY5740A EBX SBC User’s Manual V1.1 1.2 Block Diagram www.perfectron.com...

  • Page 9: Board Placement

    OXY5740A EBX SBC User’s Manual V1.1 1.3 Board Placement www.perfectron.com...

  • Page 10: Chapter 2: Jumpers And Connectors

    OXY5740A EBX SBC User’s Manual V1.1 Chapter 2 : Jumpers and Connectors 2.1 Jumpers and connectors list Label Function BAT1 BATTERY connector DIMM0 DDR4 SO DIMM Socket DIMM1 DDR4 XR DIMM Socket CN19 LVDS CONNECTOR MCARD1 Mini PCIE Card Slot<Full size Co-lay mSATA>...
  • Page 11 OXY5740A EBX SBC User’s Manual V1.1 CN22 4P DC Terminal Block connector CPU FAN CPU FAN CONNECTOR FPE1 StackPC FPE Top Connector CON_A1 StackPC LED1 LAN1 LED STATUS LED2 LAN2 LED STATUS LED3 POWER/HDD LED POWER BUTTON CN18 LVDS POWER BOX HEADER...

  • Page 12: Jumper Settings

    OXY5740A EBX SBC User’s Manual V1.1 2.2 Jumper Settings CN2: LVDS Connector PIN DEFINITION PIN DEFINITION LVDS_BCLK LVDS_BCLK# LVDS_A3 LVDS_A3# LVDS_B3 LVDS_B3# LVDS_ACLK LVDS_B2 LVDS_ ACLK # LVDS_B2# LVDS_B1 LVDS_A2 LVDS_B1# LVDS_A2# LVDS_B0 LVDS_A1 LVDS_B0# LVDS_A1# LVDS_A0 LVDS_DCC_SC LVDS_A0# LVDS_DCC_SD...
  • Page 13 OXY5740A EBX SBC User’s Manual V1.1 CN18: Inverter connector PIN DEFINITION 1 12V 2 12V 3 12V 4 5VS 5 5VS 6 GND 7 GND 8 BL_EN 9 LVDS_BKL_CTRL_R 10 GND CPU FAN: CPU FAN Connector DEFINITION CPUFAN_PWN CPUFAN_IO CPUFAN_VCC...
  • Page 14 OXY5740A EBX SBC User’s Manual V1.1 JP14: MCARD1 mSATA and mPCIe selection Jumper Function description Setting mPCIe mSATA Default setting: 1-2 MCARD1: Mini PCIE Card Slot<COLAY M SATA> www.perfectron.com...
  • Page 15 OXY5740A EBX SBC User’s Manual V1.1 MCARD2: Mini PCIE Card Slot www.perfectron.com...
  • Page 16 OXY5740A EBX SBC User’s Manual V1.1 LAN1: Intel I219LM / LAN2: Intel I210IT CN20: USB 2.0 PIN DEFINITION 1 5V 2 USB1- 3 USB1+ 4 GND 5 GND 6 5V 7 USB2- 8 USB2+ 9 GND 10 GND CN21: USB 2.0...
  • Page 17 OXY5740A EBX SBC User’s Manual V1.1 CN8: USB3.0 * 2 CN9: USB3.0 * 2 CN6: Audio Jacks Connector (MIC) CN7: Audio Jacks Connector (Line-Out) www.perfectron.com...
  • Page 18 OXY5740A EBX SBC User’s Manual V1.1 CN22: DC Adapter Power Input DC_JACK1: DC-IN CN10: LPC (Update BIOS) DP1: DISPLAY PORT www.perfectron.com...
  • Page 19 OXY5740A EBX SBC User’s Manual V1.1 DP2: DISPLAY PORT SIM_CARD1: SIM card socket DVI: DVI-D www.perfectron.com...
  • Page 20 OXY5740A EBX SBC User’s Manual V1.1 COM1: RS232/422/485 with 5V/12V selectable JP4: COM1 5V/12V selection JP5: COM2 5V/12V selection COM2: RS232, with 5V/12V selectable COM3/4: RS232 www.perfectron.com...
  • Page 21 OXY5740A EBX SBC User’s Manual V1.1 CON A1: CONNECTOR A TOP www.perfectron.com...
  • Page 22 OXY5740A EBX SBC User’s Manual V1.1 FPE1: StackPC FPE Top Connector www.perfectron.com...
  • Page 23 OXY5740A EBX SBC User’s Manual V1.1 LED1: LAN1 LED STATUS LED2: LAN2 LED STATUS LED3: POWER/HDD LED SW1: POWER BUTTON FP1: Front Panel www.perfectron.com...
  • Page 24 OXY5740A EBX SBC User’s Manual V1.1 FP2: LAN LED Plug LED cable to FP2 pin header Active LED: plug 1-3 pin Single 1000M LED: plug 1-5 pin Single 100M LED: plug 1-7 pin Dual 1000M LED: plug 5-7 pin www.perfectron.com...

  • Page 25: Chapter 3: Getting Started

    OXY5740A EBX SBC User’s Manual V1.1 Chapter 3: Getting Started 3.1 Installing System Memory The OXY5740A supports 1 x DDR4 XR-DIMM up to 16GB (Top Side), 1 x DDR4 SODIMM up to 16GB. To install a memory module: 1. Located the memory module slots on the motherboard.
  • Page 26 OXY5740A EBX SBC User’s Manual V1.1 3. Insert the module firmly into the desired slot until the slot lock and secure the memory module. 4. After insert the module to the desire slot, drive screws tighten with memory module’s crew hole and bolt on PCB board.

  • Page 27: Chapter 4: Jumpers And Connectors

    OXY5740A EBX SBC User’s Manual V1.1 Chapter 4: AMI BIOS UTILITY This chapter provides users with detailed descriptions on how to set up a basic system configuration through the AMI BIOS setup utility. 4.1 Starting To enter the setup screens, perform the following steps: •...

  • Page 28: Mani Menu

    OXY5740A EBX SBC User’s Manual V1.1 4.3 Main Menu The Main menu is the screen that first displays when BIOS Setup is entered, unless an error has occurred. System Date Use this function to change the system date. Select System Date using the Up and Down <Arrow> keys. Enter the new values through the keyboard.

  • Page 29: Advanced Menu

    OXY5740A EBX SBC User’s Manual V1.1 4.4 Advanced Menu The Advanced Menu allows you to configure your system for basic operation. Some entries are defaults required by the system board, while others, if enabled, will improve the performance of your system or let you set some features according to your preference.

  • Page 30: Cpu Configuration

    OXY5740A EBX SBC User’s Manual V1.1 4.4.1 CPU Configuration 4.4.2 Power & Performance www.perfectron.com...

  • Page 31: Pch-Fw Configuration

    OXY5740A EBX SBC User’s Manual V1.1 4.4.3 PCH-FW Configuration 4.4.4 ACPI Setting www.perfectron.com...

  • Page 32: It8786 Super Io Configuration

    OXY5740A EBX SBC User’s Manual V1.1 4.4.5 IT8786 Super IO Configuration User can choose a mode (RS232/RS422/RS485) on each serial port www.perfectron.com...
  • Page 33 OXY5740A EBX SBC User’s Manual V1.1 www.perfectron.com...

  • Page 34: Hardware Monitor

    OXY5740A EBX SBC User’s Manual V1.1 4.4.6 Hardware Monitor www.perfectron.com...

  • Page 35: Csm Configuration

    OXY5740A EBX SBC User’s Manual V1.1 4.4.7 CSM Configuration www.perfectron.com...

  • Page 36: Chipset

    OXY5740A EBX SBC User’s Manual V1.1 4.5 Chipset 4.5.1 SA Configuration www.perfectron.com...

  • Page 37: Graphics Configuration

    OXY5740A EBX SBC User’s Manual V1.1 4.5.1.1 Graphics Configuration 4.5.1.2 LCD Control www.perfectron.com...

  • Page 38: Pch-Io Configuration

    OXY5740A EBX SBC User’s Manual V1.1 Primary IGFX Boot Display: Select the Video Device which will be activated during POST. This has no effect if external graphics present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display.
  • Page 39 OXY5740A EBX SBC User’s Manual V1.1 4.6 Security www.perfectron.com...
  • Page 40 OXY5740A EBX SBC User’s Manual V1.1 4.7 Boot Bootup NumLock State: Select the keyboard NumLock state. Quiet Boot: Enables or disables Quiet Boot option. Fast Boot: Enables or disables boot with initialization of a minimal set of devices required to launch active boot option.
  • Page 41 OXY5740A EBX SBC User’s Manual V1.1 4.8 Save & Exit This screen provides functions for handling changes made to the BIOS settings and the exiting of the Setup program. Save Changes and Exit: Exit system setup after saving the changes.
