Nov. 2009
SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 12
[VERSION LIST]
Model
Version
USA-01
IC-FR5000
EXP-01
CHN-01
IC-FR5100
EUR-01
Frequency
Channel
TX Power
range
spacing
(MHz)
(kHz)
7.5/15/30
12.5/25.0
136–174
7.5/15/30
12.5/20/25
(W)
50
25
