Icom IC-FR5000 Service Manual Addendum page 3

July 2016
SECTION 8
[CHASSIS PARTS]
REF PART
NO. NO.
W1 8920001170 CAB-1147
MP1 8810003361 SET SCREWC M3 X 6 ZC3
MP2 8810003361 SET SCREWC M3 X 6 ZC3
MP3 8110009330 3063 U-COVER
MP4 8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110010730 3063 A-BOTTOM COVER
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
8110009340 3063 BOTTOM COVER D
MP5 8930073980 3063 ANGLE
MP6 8930073990 3063 CENTER ANGLE
MP7 8810005771 BIND M3 X 8 ZK3BLACK
MP9 8810009061 FLAT M3 X 6 ZK3
MP10 8810008661 PHBT M3 X 8 NI-ZC3
MP11 8810003361 SET SCREWC M3 X 6 ZC3
MP12 8810003361 SET SCREWC M3 X 6 ZC3
MP13 8930091270 3063 PLATE (NC)Y3008
MP14 8810008661 PHBT M3 X 8 NI-ZC3
MP15 8930091280 3063 SHEETOnly [#07]
[CONNECT UNIT]
REF PART
NO. NO.
J601* 6510027920 IMSA-9631S-28Y934
J602 6510023210 CD6125SA1J0
S1* 2260003070 MINISMDC150F/24-2
W601 8900017500 OPC-1852 (P0.5N28L90)
[FAN UNIT]
REF PART
NO. NO.
J1 6510011441 B4P-VH (LF) (SN)
J2 6510009371 B4B-ZR (LF) (SN)
J3 6510009371 B4B-ZR (LF) (SN)
MP1 8930073170 SPONGE (JQ)
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
(Replacement page)
MECHANICAL PARTS
DESCRIPTION QTY.
Only [#07] 1
4
1
1
[#01] 1
[#03] 1
[#04] 1
[#07] 1
[#14] 1
[#15] 1
[#16] 1
[#22] 1
[#23] 1
[#32] 1
[#33] 1
[#34] 1
[#35] 1
[#36] 1
[#37] 1
[#81] 1
[#82] 1
2
1
11
7
2
Only [#82] 6
Only [#07] 1
Only [#07] 1
Only [#07] 2
2
DESCRIPTION QTY.
DESCRIPTION QTY.
1
1
1
1
[FRONT UNIT]
REF PART
NO. NO.
J501* 6510019121 S8B-PH-SM4-TB (LF) (SN)
J502* 6510019121 S8B-PH-SM4-TB (LF) (SN)
J503 6450002210 3017-8821
J504* 6510014961 B2B-ZR-SM4-TF (LF) (SN)
DS500 5030004230 L5-1077TRR
DS501 5040002710 EMPG3338S
DS502 5040002720 EMVR3338S
DS503 5040002710 EMPG3338S
DS504 5040002720 EMVR3338S
DS511 5040002150 VRPG3349S-734
DS512 5040002150 VRPG3349S-734
S506 2250000511 RH70N1037E20-13F-2781
SP501 2510001910 ND3050GA13Y04
MF1 2710001020 MGT6012HR-O15
MF2 2710001020 MGT6012HR-O15
W501 8900011801 OPC-1199A
W502 8900017541 OPC-1785-1
EP501 8930065150 SRCN-2781-SP-N-W (SHJ)
EP503 6910019600 LM-5
EP504 6910019610 LM-7 (SPACER)
MP501 8930064260 2781 LCD HOLDER Y753
MP502 8210021190 2781 REFLECTOR
MP503 8610012161 KNOB N-324-1
MP504 8610012151 KNOB N-325-1
MP507 8930064220 2781 KNOB RUBBER (TOP)S
MP508 8930075200 HIMELON SHEET (CY)
MP510 8930059001 2601 SP NET-1
MP511 8210025550 3063 FRONT PANEL (A)
MP512 8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
8930074161 3063 FRONT PLATE-1
1
8930074161 3063 FRONT PLATE-1
1
8930074161 3063 FRONT PLATE-1
MP513 8310070870 3063 WINDOW PLATE
1
8310070870 3063 WINDOW PLATE
8310070870 3063 WINDOW PLATE
1
8310070870 3063 WINDOW PLATE
8310070870 3063 WINDOW PLATE
8310070870 3063 WINDOW PLATE
8310070870 3063 WINDOW PLATE
8310070870 3063 WINDOW PLATE
8310070870 3063 WINDOW PLATE
8310083780 3063 WINDOW PLATE (A)
8310083780 3063 WINDOW PLATE (A)
8310083780 3063 WINDOW PLATE (A)
8310083780 3063 WINDOW PLATE (A)
8310083780 3063 WINDOW PLATE (A)
8310083780 3063 WINDOW PLATE (A)
8310083780 3063 WINDOW PLATE (A)
8310083780 3063 WINDOW PLATE (A)
MP514 8210024431 3063 M-PANEL-1
MP515 8930074000 3063 SP ANGLE
MP516 8110009350 3063 FRONT COVER Y2145
MP517 8930073820 3063 FRONT KEY (SC)
MP518 8930073911 3063 M-COVER-1
MP519 8930074020 3063 KNOB RUBBER (TOP)
MP520 8930075010 3063 A-PACKING (TOP)
MP529 8810008661 PHBT M3 X 8 NI-ZC3
MP530 8810008661 PHBT M3 X 8 NI-ZC3
MP531 8810008661 PHBT M3 X 8 NI-ZC3
MP532 8810008661 PHBT M3 X 8 NI-ZC3
MP533 8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
8810008661 PHBT M3 X 8 NI-ZC3
MP534 8810010780 PH BT M3 X20 NI-ZK3
MP535 8930091230 3705 FRONT NET
MP536 8930091630 2781 LCD FILTER
8-1
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
Only [#07] 1
Only [#07] 1
1
1
2
2
4
1
1
1
1
1
2
1
1
[#14] 1
[#15] 1
[#16] 1
[#23] 1
[#35] 1
[#36] 1
[#37] 1
[#01] 1
[#03] 1
[#04] 1
[#07] 1
[#14] 1
[#15] 1
[#16] 1
[#22] 1
[#23] 1
[#32] 1
[#33] 1
[#34] 1
[#35] 1
[#36] 1
[#37] 1
[#81] 1
[#82] 1
1
1
1
1
1
1
1
6
2
4
6
[#14] 5
[#15] 5
[#16] 5
[#23] 5
[#35] 5
[#36] 5
[#37] 5
Only [#07] 4
Only [#07] 1
1
