Icom IC-FR5000 Service Manual Addendum page 11

July 2016
[FRONT UNIT]
REF PART
DESCRIPTION
NO. NO.
J504 6510014961 S.CON B2B-ZR-SM4-TF(LF)(SN)
DS500 5030004230 LCD L5-1077TRR
DS501 5040002710 LED EMPG3338S
DS502 5040002720 LED EMVR3338S
DS503 5040002710 LED EMPG3338S
DS504 5040002720 LED EMVR3338S
DS505 5040002310 S.LED SML-311YTT86
DS506 5040002310 S.LED SML-311YTT86
DS507 5040002310 S.LED SML-311YTT86
DS508 5040002310 S.LED SML-311YTT86
DS509 5040002310 S.LED SML-311YTT86
DS510 5040002310 S.LED SML-311YTT86
DS511 5040002150 LED VRPG3349S-734
DS512 5040002150 LED VRPG3349S-734
S506 2250000511 ENC RH70N1037E20-13F-2781
SP501 2510001910 SPE ND3050GA13Y04
MF1 2710001020 FAN MGT6012HR-O15
MF2 2710001020 FAN MGT6012HR-O15
W501 8900011801 CAB OPC-1199A
W502 8900017541 CAB OPC-1785-1
EP501 8930065150 LCD SRCN-2781-SP-N-W (SHJ)
EP503 6910019600 SPA LM-5
EP504 6910019610 SPA LM-7 (SPACER)
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on PART orders and repairs.
(Amended page)
[CONNECT UNIT]
H/V REF
M.
LOCATION NO.
B 18.4/57.1 C601
C602
C603
C604
C605
C606
C607
C608
T 111.3/43.2 C609
T 101.3/43.2 C610
T 91.3/43.2 C611
T 81.3/43.2 C612
T 71.3/43.2 C613
T 61.3/43.2 C614
C615
C616
C617
C618
C619
C620
C621
J601
Only [#07] J602
Only [#07]
S1
W601
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
2
PART
DESCRIPTION
NO.
4030017420 S.CER C1005 CH 1H 470J-T
4030017400 S.CER C1005 CH 1H 220J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017400 S.CER C1005 CH 1H 220J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
4030017420 S.CER C1005 CH 1H 470J-T
6510027920 S.CON IMSA-9631S-28Y934
6510023210 CON CD6125SA1J0
2260003070 S.SWI MINISMDC150F/24-2
8900017500 CAB OPC-1852 (P0.5N28L90)
H/V
M.
LOCATION
T 13.8/12.4
T 12.2/12.4
T 16.6/12.4
T 15.0/14.2
T 17.8/13.9
T 19.4/12.4
T 20.6/13.9
T 22.7/12.4
T 25.5/12.4
T 29.7/12.8
T 31.0/14.1
T 32.5/12.8
T 33.6/14.1
T 35.2/14.1
T 35.8/12.8
B 35.2/15.6
T 37.6/13.6
T 39.3/12.2
T 39.9/13.4
T 41.3/12.6
T 27.4/13.9
B 22.8/16.2
B 38.9/18.0
S.=Surface mount
