Camden - 5 Drawer Mirror Chest
Assembly Instructions -
Dimensions
Width - 80cm
Depth - 39cm
Height - 101.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
239/9472
MADE IN
BRITAIN
Issue 1 - 20/06/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Camden 239/9472
Summary of Contents for Argos Camden 239/9472
- Page 1 Camden - 5 Drawer Mirror Chest Assembly Instructions - 239/9472 Please keep for future reference Dimensions Width - 80cm Depth - 39cm MADE IN Height - 101.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 20/06/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 38kgs. Please lift space to layout the parts before recommend the with care.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below (D1991A) (796 x 391mm) Left Side Right Side Plinth (D1992A) (D1993A) (D1994A) (979 x 389mm)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 5 drawer fronts Screw 2 metal dowels into the holes shown on the back of each drawer front Note: Tighten metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Warning: Glass! Handle with care Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the...
- Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the drawer assemblies over and fit 4 wedgefixes Slide 2 wedgefixes into the small groove located on the back of the drawer front 2 wedgefixes into the small groove in the drawer back Once in place, tighten up the screws in the wedgefixes...
- Page 8 Assembly Instructions Step 9 screw screw screw Prepare the left side Fit the 5 runners to the left side The 1st screw uses Finished the 1st hole in from the front edge front of the runner The 2nd and 3rd screw use the holes that line up with the other panel holes.
- Page 9 Assembly Instructions Step 10 Prepare the right side Fit the 5 runners to the right side The 1st screw uses Finished front edge the 1st hole in from the front of the runner The 2nd and 3rd screw screw screw screw use the holes that line up with the other panel...
- Page 10 Assembly Instructions Step 11 Prepare the top Screw 4 small metal dowels into the holes on the top Note: Tighten metal dowels up fully against the panels. Fix the bracket flush to the front edge of the Finished groove in the top front edge 398mm in from the side, using screw...
- Page 11 Assembly Instructions Step 13 Prepare the plinths Tap 2 wooden dowels into the ends of the 2 plinths Insert 2 large locking nuts into each plinth Note: The arrow on the locking nut must point towards the hole in the edge of the panel.
- Page 12 Assembly Instructions Step 15 Fit the left side 2 people are needed here Push the left side onto the assembly. Note: You will need to slide the 2 small metal dowels fitted to the into the top of the 2 hollow core locking nuts Insert a screwdriver into the 2 hollow core locking...
- Page 13 Assembly Instructions Step 16 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that measurement x to x equals y to y.
- Page 14 Assembly Instructions Step 17 Secure unit to a wall To prevent possible overbalancing we recommend that this unit is secured to a suitable wall by use of the metal bracket fitted to the top of the unit Fixings are not supplied as they will need to suit the wall type, and the length of screw will...
- Page 15 Assembly Instructions Step 18 Fit the drawers Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position. Side panel Drawer...
- Page 16 KEEP THESE INSTRUCTIONS FOR FUTURE USE If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3071...
