Executive Gas Lift Bar Stool
Assembly Instructions
Dimensions
Width - 51cm
Depth - 51cm
Height - 87.5-107.5cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
- Please keep for future reference
600/0372
600/1522
239/6011
Issue 1 - 28/04/14
Advertisement
Related Manuals for Argos 600/037
Summary of Contents for Argos 600/037
- Page 1 Width - 51cm Depth - 51cm Height - 87.5-107.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800 Issue 1 - 28/04/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • During assembly do not stand • To reduce the • Check you have all the components and tools listed on or put weight on the product, this likelihood of the following pages.
-
Page 3: Components - Parts
Components - Parts If you have damaged or missing components, call the Customer Helpline: Argos = 0345 640 0800 Please check you have all the parts listed below Seat Upper leg Gas lift (51 x 44.5 x 36cm) (29.5 x 21.5 x 40.5cm) (Ø5 x 46-67cm) - Page 4 Assembly Instructions Step 1 Attaching upper leg Place the seat upside down on a raised, flat and protected surface. Position the upper leg and make sure that the lever is at your right hand side as shown in the diagram. Secure using bolts tighten bolts using allen Lever...
- Page 5 To lower the seat, lift up the lever while seated on Lever the stool. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800...
- Page 6 Executive Bar Stool With Back Rest Assembly Instructions 600/1522 Please keep for future reference Dimensions Width - 52cm Depth -54.5cm Height - 84/106cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800...
- Page 7 Safety and Care Advice Important – Please read these instructions fully before starting assembly components and tools listed on the product during assembly, recommend the page 2. this could cause damage. use of power drill/drivers for inserting screws, plastic bags and separate them to its nal position (in the same as this could damage the unit.
- Page 8 Components - Parts Please check you have all the parts listed below Back x 1 Seat x 1 Cover x 1 ( 52X32cm ) ( 39X39cm ) Base x 1 Seat support x 1 Gas lift x 1 ( D500mm ) ( 220mm ) Fittings Components -...
- Page 9 Assembly Instructions Step 1 Fitting the gaslift Take off the cap on the top of gaslift Insert the gaslift into the base . Then slide the cover over the top. Ensure the gas lift is NOTE: fully inserted and well fitted. Step 2 Fitting the seat Use the bolts...
- Page 10 Assembly Instructions Step 3 Fitting the seat support Use the bolts and washers to fix the seat support Step 4 Fitting the Unit Carefully locate the seat onto the base unit.
- Page 11 Finishing the Unit Carefully place the unit in the desired location. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 489-499 Avebury Boulevard Milton Keynes MK9 2NW, Argos Limited...
