3 Door Tall Robe
Assembly Instructions -
Dimensions
Width - 149.5cm
Depth - 50cm
Height - 199.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
274/9668
259/2468
239/2819
355/1288
330/5386
355/3262
MADE IN
BRITAIN
Issue 8 - 19/01/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 274/9668
Summary of Contents for Argos 274/9668
- Page 1 3 Door Tall Robe Assembly Instructions - 274/9668 Please keep for future reference 259/2468 239/2819 355/1288 330/5386 355/3262 Dimensions Width - 149.5cm Depth - 50cm MADE IN Height - 199.5cm BRITAIN Important - Please read these instructions fully before starting assembly...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 89kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Large Shelf (D2052A) (965 x 467mm) 5 Back Rail (D2053A) (965 x 120mm) Left Side Right Side...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the divider Screw a metal dowel into the divider Note: Tighten metal dowels up fully against the panel. Fit 4 hinge plates onto the divider...
- Page 6 Assembly Instructions Step 3 Fit the base to the divider Push the base onto the divider secure with 2 screws Finished front edge p l a i n c h i p a r d s u r f a c Finished front edge Step 4...
- Page 7 Assembly Instructions Step 5 Prepare the right side Screw 3 metal dowels into the right side Insert 2 large locking These 2 holes nuts into the right are not used side Fit 4 hinge plates onto the right side , making sure that the slot is facing towards the finished front edge.
- Page 8 Assembly Instructions Step 7 Prepare the plinth Insert 2 large locking nuts into the plinth Tap 2 wooden dowels into the plinth Step 8 Fit the plinth Push the plinth onto the right side Use a screwdriver to tighten the large locking fitted to the plinth Step 9 Prepare the back rail...
- Page 9 Assembly Instructions Step 10 Finished front edge Fit the back rail to the left side Push the back rail Finished onto the left side front edge Use a screwdriver to tighten the large locking fitted to the back rail Step 11 Fit the left side Push the left side onto the base...
- Page 10 Assembly Instructions Step 12 Prepare the top Screw 6 metal dowels into the top Rounded front edge Step 13 Fit the top and plastic nails Push the top onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted to the left side , right...
- Page 11 Assembly Instructions Step 14 Fit back panels The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x:x equals y:y.
- Page 12 Assembly Instructions Step 15 Short Rail Fit the hanging rails Position 1 Long Rail You can fit the 2 long Short Rail Position 1 hanging rails and 2 Position 2 short hanging rails Long Rail using any of the 4 Position 2 positions shown opposite.
- Page 13 Assembly Instructions Step 16 Fit the shelves Small shelf Insert 4 shelf studs Position 1 position 1 or 2 for the large shelf and the small shelf Lower the large shelf Small shelf Large shelf and the small shelf Position 2 Position 1 down onto the shelf studs...
- Page 14 Assembly Instructions Step 18 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 15 Assembly Instructions Step 19 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 16 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3005...
