Malibu - Media Unit
Assembly Instructions -
Dimensions
Width - 75cm
Depth - 40cm
Height - 41cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
259/7937
278/5079
238/3172
228/8284
259/8967
275/3953
MADE IN
BRITAIN
Issue 3 - 04/09/14
Advertisement
Related Manuals for Argos Malibu 259/7937
Summary of Contents for Argos Malibu 259/7937
- Page 1 Malibu - Media Unit Assembly Instructions - 259/7937 Please keep for future reference 278/5079 238/3172 228/8284 259/8967 275/3953 Dimensions Width - 75cm Depth - 40cm MADE IN Height - 41cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 3 - 04/09/14...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 15.5kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (D2864A) (D2565A) (D2863A) (396 x 394mm) (396 x 394mm) (747 x 396mm) Divider...
-
Page 4: Tools Required
If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left side Place a runner the left side shown. Slide back the top of runner and use the Finished 2nd hole from the front front edge to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
- Page 8 Assembly Instructions Step 9 Prepare the right side Place a runner the right side shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 9 Assembly Instructions Step 12 Prepare the 3 rails Tap 2 wooden dowels into each of the 3 rails . Finished front edge Step 13 Fit the 3 rails to the right side Push the 3 rails onto p l a i n c the right side h i p...
- Page 10 Assembly Instructions Step 15 Prepare the top Screw 6 metal dowels into the top Finished front edge Step 16 Prepare the divider Tap a wooden dowel into the divider Insert 2 large locking Finished nuts into the divider front edge Step 17 Fit the divider to the Push the divider...
- Page 11 Assembly Instructions Step 18 Fit the top Lower the top down onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the sides Carefully lay the unit back down onto its front edges for the next step.
- Page 12 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3036...
