Two Drawer TV Unit
Assembly Instructions
237/9430
- Please keep for future reference
Dimensions
Width - 100cm
Depth - 40cm
Height - 45cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Issue 1 - 10/04/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 237/9430
Summary of Contents for Argos 237/9430
- Page 1 Two Drawer TV Unit Assembly Instructions 237/9430 - Please keep for future reference Dimensions Width - 100cm Depth - 40cm Height - 45cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not recommend the components and tools listed on the product, this could cause pages 2 and 3. - Page 3 Components - Panels Please check you have all the panels listed below Foot Support panel Divider Shelf (918 x 362mm) (36 x 36mm) (160 x 70mm) (347 x 195mm) Front rail Rear rail (918 x 80mm) (918 x 80mm) Top panel (1000 x 400mm) Left side panel Right side panel...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Note: The quantities below are the correct amount to complete the assembly. In some cases more Runner inner piece x 4 Runner outer piece x 4 12mm Screw x 37 Large metal cam x 15...
- Page 5 Assembly Instructions Step 1 Dis-assemble Runners To disassemble the runners pull out the inner piece of runners, to seperate the Inner piece and the Outer piece , push and hold the tab and then pull completely out as shown. Step 2 Screw Support panel to Shelf using...
- Page 6 Assembly Instructions Step 3 Screw metal dowels into Shelf as shown. Note: Insert metal dowels as far as shown. Do not over tighten. Firmly push wood dowels into indicated holes. Step 4 Position Runner outer piece onto Divider and fix through the indicated holes shown using Screws Note: Make sure the front...
- Page 7 Assembly Instructions Step 6 Firmly push Divider Taped edge onto Shelf , make face upwards. sure the wood and metal dowels enter corresponding holes. Long leg. Insert Large metal Cams into the holes on Divider so that they are flush. Note: Longer leg of the cross on the Metal...
- Page 8 Assembly Instructions Step 8 Firmly push wood dowels into the indicated holes in Divider Firmly push Front and Rear rails onto the dowels on Divider, make sure the dowels enter corresponding holes. Secure with Screws Note: Cut out on the corner of rails should Cut out on the corner face outwards as...
- Page 9 Assembly Instructions Step 10 Screw metal dowels into Left side panel as shown. Firmly push wood dowels into indicated holes. Step 11 Lift the end of panels a little to easily fitting dowels Two people may be into corresponding holes. needed here.
- Page 10 Assembly Instructions Step 13 Screw metal dowels into Top panel as shown. Firmly push wood dowels into indicated holes. Step 14 Two people may be needed here. Turn over the Top panel. Firmly push Top panel onto Side panels and support panel make sure the wood and metal dowels enter corresponding holes.
- Page 11 Assembly Instructions Step 15 Attach back panel to back of the unit using Screws Step 16 Position Runner inner piece onto Drawer side panels fix through the indicated holes shown using Screws Note: Make sure the front end of Runner is flush with the front edge of drawer side as shown.
- Page 12 Assembly Instructions Step 17 Drawer assembly Firmly push wood dowels into the indicated holes in Drawer back panel Fix drawer sides 11 12 to Drawer back panel using screws Slide Drawer base into the grooves as shown. Foiled side face upwards. Screw Metal dowels into holes...
- Page 13 Assembly Instructions Step 18 Slide Drawer into the space as shown, make sure the Runner inner piece enters the Runner outer piece on both side. Note: Please notice the left and right drawer position, do not reverse. Please notice the left and right drawer position, do not reverse.
