Linear - 3 Door Mirror Robe
Assembly Instructions -
Dimensions
Width - 119cm
Depth - 49cm
Height - 184cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
276/3503
249/3347
237/7432
MADE IN
BRITAIN
Issue 2 - 30/07/14
Advertisement
Related Manuals for Argos Linear 276/3503
Summary of Contents for Argos Linear 276/3503
- Page 1 Linear - 3 Door Mirror Robe Assembly Instructions - 276/3503 Please keep for future reference 249/3347 237/7432 Dimensions Width - 119cm Depth - 49cm MADE IN Height - 184cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 2 - 30/07/14...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 76kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Fixed Shelf (DF155) (759 x 465mm) Loose Shelf (DF852) (378 x 465mm) Left Side Divider Right Side...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the divider Tap 4 wooden dowels into the divider Note: Wooden dowels must not stick out from the edge by more than 10mm or they may damage other panels.
- Page 6 Assembly Instructions Step 2 Prepare the left side Tap 4 wooden dowels into the left side Finished front edge Screw 2 metal dowels into the left side To fit the rail holder screw through the top hole with screw into the mark hole drilled in the left side .
- Page 7 Assembly Instructions Step 4 Fit the fixed shelf to the divider Push the fixed shelf onto the divider Use a screwdriver to tighten the 2 large locking nuts fitted to the fixed shelf Finished front edge Note: Turn the large Finished locking nuts as far as...
- Page 8 Assembly Instructions Step 6 Fit the base Fit the base onto the assembly using 4 screws Polystyrene block Finished Note: To make it easier Polystyrene front edge to fit the top and base block panels, place polystyrene blocks from the packaging underneath the side panels and divider to raise the assembly.
- Page 9 Assembly Instructions Step 8 Fit the right side Fit the right side the base using 2 screws Note: Place polystyrene blocks underneath the right side . Step 9 Prepare the top Screw 6 metal dowels into the top Finished front edge...
- Page 10 Assembly Instructions Step 10 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 6 large locking nuts fitted to the left side , upright and right side Finished front edge Step 11 Fit the feet Fit the feet to the base...
- Page 11 Assembly Instructions Step 12 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back panels Square up the unit by making sure that measurement x:x equals y:y.
- Page 12 Assembly Instructions Step 13 Fit the shelf studs For each of the 3 loose shelves , insert 4 shelf studs Step 14 Fit the loose shelves Lower the 3 loose shelves down onto the shelf studs...
- Page 13 Assembly Instructions Step 15 Fit the hanging rail Push the hanging rail into the rail holders fitted to the left side and divider. Step 16 Fit the handles to the 2 plain doors Attach the handles using the 2 outer screws 1st.
- Page 14 Assembly Instructions Step 17 Fit the hinges to the doors Note: To make it easier to fit the hinges and to Polystyrene protect the handles, blocks place polystyrene blocks from the packaging underneath the 2 plain doors to raise them up. Push fit 4 hinges into each of the 3 doors...
- Page 15 Assembly Instructions Step 18 Fit the doors Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 16 Assembly Instructions Step 19 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 17 Assembly Instructions Step 20 Fit the bracket To prevent possible overbalancing, we recommend that this unit is secured to a suitable wall by use of the bracket fitted to the top of the unit. Fixings are not supplied, as they will need to suit the wall type and the length of screw will depend on the distance...
- Page 18 KEEP THESE INSTRUCTIONS FOR FUTURE USE If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR3054...
