New Sywell - Dresser and Stool
Assembly Instructions -
Dresser
Dimensions
Width - 77.5cm
Depth - 40cm
Height - 74.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
Stool
Dimensions
Width - 43cm
Depth - 35.5cm
Height - 48cm
239/6994
259/7975
247/9684
258/7040
MADE IN
BRITAIN
Issue 1 - 03/06/14
Advertisement
Related Manuals for Argos New Sywell 239/6994
Summary of Contents for Argos New Sywell 239/6994
- Page 1 New Sywell - Dresser and Stool Assembly Instructions - 239/6994 Please keep for future reference 259/7975 247/9684 258/7040 Dresser Stool Dimensions Dimensions Width - 77.5cm Width - 43cm Depth - 40cm Depth - 35.5cm MADE IN Height - 74.5cm Height - 48cm BRITAIN Important - Please read these instructions fully before starting assembly...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 24kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (DF745) (DF746) (DF1348) (745 x 396mm) (745 x 396mm) (745 x 396mm) Modesty...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 2 drawer fronts Screw 2 metal dowels into each of the 2 drawer fronts Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer bases Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer backs Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left side Place a runner the left side . Slide back the top of the runner and use the 2nd Finished hole from the front to fit front edge the 1st screw Slide the runner back the other way and fit the 2nd screw into...
- Page 8 Assembly Instructions Step 9 Prepare the right side Place a runner the right side Slide back the top of runner and use the 2nd Finished hole from the front to fit front edge the 1st screw Slide the runner back the other way and fit the 2nd screw into the corresponding hole...
- Page 9 Assembly Instructions Step 10 Prepare the top Tap 2 wooden dowels into the top Note: Wooden dowels must not stick out from the edge by more than 10mm or they may Finished damage other panels. front edge Screw 2 metal dowels into the top Insert 4 large locking nuts...
- Page 10 Assembly Instructions Step 12 Note: Due to the manufacturing process, the 2 holes for Prepare the divider the large locking nut can be on either surface of the divider. Place a runner the divider as shown. Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw...
- Page 11 Assembly Instructions Step 13 Note: The large locking nuts can be on either surface of the divider. Fit the divider Push the divider onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to the divider Finished front edge Step 14...
- Page 12 Assembly Instructions Step 16 Prepare the modesty Insert 4 arge locking nuts into the modesty Step 17 Fit the rail Push the modesty onto the right side Use a screwdriver to tighten the large locking fitted to the modesty Step 18 Fit the left side Push the left side onto the assembly.
- Page 13 Assembly Instructions Step 19 Fit the plastic nails Tap 2 plastic nails into the bottom edge of each of the sides as shown. Step 20 Fit the drawers Slide both of the runners forward and locate the drawer sides between them, lining up the holes in the drawer sides with the 2nd 'threaded' holes in...
- Page 14 Assembly Instructions Step 21 Fit the bracket To prevent possible overbalancing we recommend that this unit is secured to a suitable wall using the bracket fitted just below the modesty, on one of the side panels with the screw Fixings are not supplied as they will need to suit the wall type, and the length of screw will...
- Page 15 Assembly Instructions Step 22 Prepare the 2 stool sides Screw 6 metal dowels into each of the 2 stool sides , as shown. Step 23 Prepare the stool base Insert 4 large locking nuts into the holes in the stool base Tap 2 wooden dowels into the ends of the stool base...
- Page 16 Assembly Instructions Step 26 Fit the 2 stool rails Push the 2 stool rails down onto the stool side , as shown. Use a screwdriver to tighten the 2 large locking nuts fitted to each stool rail Step 27 Fit the other stool side Push the other stool side...
- Page 17 Assembly Instructions Step 28 Fit the seat pad Position the seat pad onto the assembly and make sure that its 4 edges line up with the stool base Soft Hold the seat pad surface position and screw up through the 4 holes in Hard the stool base using...
- Page 18 Step 30 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR3017...
