New Penton - Bedside Chest
Assembly Instructions
Dimensions
Width - 45cm
Depth - 38cm
Height - 50cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
- Please keep for future reference
Customer Helpline: 08456 400 800
258/7129
237/8620
237/6684
Issue 1 - 14/05/14
Advertisement
Related Manuals for Argos New Penton 258/7129
Summary of Contents for Argos New Penton 258/7129
- Page 1 New Penton - Bedside Chest Assembly Instructions - Please keep for future reference 258/7129 237/8620 237/6684 Dimensions Width - 45cm Depth - 38cm Height - 50cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 14/05/14...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below 5 Right front frame 6 Left front frame (48 x 6.5cm) (48 x 6.5cm) 1 Top panel (45 x 38cm) underside 7 Base panel 8 Shelf (39.4 x 34.4cm) (39.4 x 34.4cm) 2 Right side panel 9 Drawer front...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fixing right front frame. (Two people required for an easier assembly). Insert right side panel into right front frame through joints. Yes! Note: Before fixing the blocks into Attention: correct place it is important to position of panel. ensure that the slot and groove of parts are fully pushed together...
- Page 6 Assembly Instructions Step 3 Insert dowels into the indicated parts. Insert shelf support pins into the right side panel and left side panel Step 4 Fitting Metal dowels. Screw metal dowels into top panel and side panels Note: Insert metal dowels as far as shown.
- Page 7 Assembly Instructions Step 5 Attention! Fixing side drawer runner. Fit side drawer runner to the right side panel then fix it using screws as shown. Attention! To the correct position of the dowel inserted in the runner, as shown in the diagram. Repeat step 5 for the left side panel and side drawer runner.
- Page 8 Assembly Instructions Step 8 Assembling the cabinet. With help, fit left side panel to the base panel and front frame , as shown. Insert 2 locking nuts into base panel where shown. Use a screwdriver to turn locking nuts clockwise to lock.
- Page 9 Assembly Instructions Step 10 Position shelf into place. Make sure round edge is facing front. Round edge. Step 11 Fixing back panel. Important: Cabinet MUST ‘square’ when back panel is attached. Attach back panel using nails...
- Page 10 Assembly Instructions Step 12 Drawer assembly. Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides and position drawer back in place. Holding the drawer back , press the drawer sides and fix them using screws Using bolts attach...
