New Hallingford - 2 Door Sliding Robe
Assembly Instructions
Dimensions
Width - 100,5cm
Depth - 60,3cm
Height -205,7cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928
For any other queries please contact the Customer Helpline on: 0345 640 2020
DR89958
- Please keep for future reference
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
2667537
2498043
2747017
2362241
2458856
Issue6 - 02/12/2016
Advertisement
Related Manuals for Argos 2667537
Summary of Contents for Argos 2667537
- Page 1 Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on •To reduce the components and tools listed on likelihood of the product, this could cause pages 2 and 3. - Page 3 Components - Panels For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the panels listed below Slide door Left side Right side Mirror slide door (205.6 x 58cm) (196.3 x 50cm) (205.6 x 58cm) (196.3 x 50cm)
-
Page 4: Tools Required
Components - Fittings For damaged or missing parts, please visit: www.argos-support.co.uk or email: Help@ClickSpares.co.uk Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Insert fittings Attach hanger rail support M using 12.5mm screw F onto sides 1 2. Note: Two pannels Screw twister leg H into sides 1 2. Note: twister leg H as far as shown. Do not over tighten. Step 2 Attaching plinths Align the sides of plinth...
- Page 6 Assembly Instructions Step 3 Insert fittings Insert expando housings B into top 5. Flip panel Carefully knock sliding rail W into top 5 by using a hammer. Reapeat b for bottom 6.
- Page 7 Assembly Instructions Step 4 Attaching panel Position top 5, bottom 6 and horizontal 7. Insert twister cam I into panels 567 where shown. Usa a screwdriver to turn Finished twister cam I clockwise front edge Temporary to lock. support Temporary support panel 7 with packaging material until attached to left side Step 5...
- Page 8 Assembly Instructions Step 6 Fitting back panel Important! Cabinet MUST A:A = B:B be ‘square’ before back is attached. Attach foldy back 8 to back of wardrobe with the coloured surface (with the Warning-label) facing the inside of the unit using nails P.
- Page 9 Assembly Instructions Step 7 Align the unit Stand up the unit Use a spirit level to check if the base of this unit is level front-to-back (1), side-to-side (2) and top-to-bottom (3) in the three positions shown. Use pegs S to level your unit in all three direction shown.
-
Page 10: Glass Handle With Care
Assembly Instructions GLASS handle with care Step 8 Insert hanger rail Place hanger rail U onto hanger rail supports M. Step 9 Insert fittings Stick felts Q onto mirror slide door 4 where shown. Insert Sliding door roller L in mirror slide door 4 on the side which is flush with. - Page 11 Assembly Instructions GLASS handle with care Step 10 Fitting handle to mirrordoor Hold hande mouldings T up against front of mirror slide door 4, make sure the ends are flush with one end of the mirror slide door Flush with end of Door Screw screws E into the ‘V’...
- Page 12 Assembly Instructions Step 13 Fitting of the doors To fit the bottom of the Doors Important! Double check if the unit is level before fitting the doors. If this is not the case This lug fits into This lug fits into please go back to the groove in the groove in...
- Page 13 Assembly Instructions Step 16 Attaching pelmet Position the pelmet @ above the unit drilling-holes and turn the screws A as far as they will go. Step 17 Attaching L-bracket Position L-Bracket G onto top 6 as shown, fix by using 15mm screw D. Note: there are no pre-drilled holes for 15mm screw D.
- Page 14 Assembly Instructions Step 18 Attaching door-stops Stick 2 door-stops onto the outside edge of each plain door to act as and side panels.
- Page 15 Assembly Instructions If your doors do not run smoothly Level & square the unit Level & square the unit up: Knock the pegs S in, as far as you require, under the ends of the unit and then snap off flush with the panel.
-
Page 16: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are suitable for supporting your unit.
