Float Table
Tools Required
Safety Glasses
Step 6 - Crank Assembly
Remove all pins and completely disas-
semble crank assembly
Some components may not be recyclable in your area.
Disassembly Instructions
Pliers
Steel
Aluminum
Aluminum
ABS
>ABS<
Page 5
Steel
ABS
>ABS<
Steel
Steel
POM
>POM<
ABS
>ABS<
REV-00
