Float Table
Tools Required
Safety Glasses
Step 13
Loosen set screw to remove torque limiter and gear box
Step 14
Remove Coil Spring, brake assembly, cable reel and load indicator
Some components may not be recyclable in your area.
Disassembly Instructions
Standard and Metric
Hex Key Set
13
Load Indicator
Coil Spring
Page 10
Steel
Brake Assembly
Cable Reel
14
REV-00
