3. insert the SD card in to the slot on the

4. If you are intending to use the internal 4G modem, insert a data Standard SIM card in to the slot on the

unit, with the logo facing the front screen side/ contact facing the rear, chamfered edge in first.

Note: Ensure the card has been activated.

5. The VBOX Sigma unit can be either powered from the 3-way hirose connector on the

supplied RLCAB010H cable which is inserted in to a vehicle's 12 V cigar power socket, from the USB socket on

the

top of the unit

using the supplied TTV1AM20MB31 cable, or through the 6-way hirose connector on

the

bottom of the unit

to the unit.

6. Configuration of VBOX Sigma is performed using a Wi-Fi hotspot created by the unit. The hotspot name and IP

address is displayed on the

Arrow Buttons

on the front of the unit. Using a phone or a computer, navigate to the Wi-Fi settings on the device

and connect to the hotspot name. Open an internet browser and enter the IP address within the address bar.

bottom of the

if being connected to another VBOX to provide NTRIP correction messages. Apply power

Network Screen

of the unit when powered, accessed by using the

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Sigma/Quick_Start_Guides/VBOX_Sigma_-

unit, more information on SD card logging is

available

here.

top of the

bottom of the unit

using the

Up or Down

_Quick_Start_Guide
