AL1024NK8QP Series
Networkable Dual Output
Power Supply/Chargers
Models Include:
AL1024NK8QP
- 12VDC and/or 24VDC (240W total power) selectable by output
- Eight (8) programmable fuse protected outputs
- Two (2) network controlled Form "C" relays
- Built-in Charger for sealed lead acid or gel type batteries
AL1024NK8DQP
- 12VDC and/or 24VDC (240W total power) selectable by output
- Eight (8) programmable Class 2 power-limited PTC protected outputs
- Two (2) network controlled Form "C" relays
- Built-in Charger for sealed lead acid or gel type batteries
Installation Guide
Rev. AL1024NK8QP-022322
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
More than just power.
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Altronix AL1024NK8QP Series
Summary of Contents for Altronix AL1024NK8QP Series
- Page 1 AL1024NK8QP Series Networkable Dual Output Power Supply/Chargers Models Include: AL1024NK8QP - 12VDC and/or 24VDC (240W total power) selectable by output - Eight (8) programmable fuse protected outputs - Two (2) network controlled Form “C” relays - Built-in Charger for sealed lead acid or gel type batteries...
- Page 2 Overview: Altronix AL1024NK8QP and AL1024NK8DQP convert a 115VAC 60Hz input into eight (8) fuse protected 12VDC or 24VDC outputs with a total of 10A max. Dual input design allows power to be steered from two (2) factory installed independent low voltage 12 or 24VDC Altronix power supplies to eight (8) independently controlled fuse (AL1024NK8QP) or PTC (AL1024NK8DQP) protected outputs.
-
Page 3: Specifications
15.5” x 12” x 4.5” • Zero voltage drop when switched over to (393.7mm x 304.8mm x 114.3mm). battery backup. Fire Alarm Disconnect: LINQ8PD(CB): • Supervised FACP disconnect (Latching or Non-Latching). • FACP reset (N.C. or N.O.). AL1024NK8QP Series Installation Guide - 3 -... -
Page 4: Installation Instructions
13. Installation of tamper switch: Mount UL Listed tamper switch (Altronix model TS112 or equivalent) at the top of the enclosure. Slide the tamper switch bracket onto the edge of the enclosure approximately 2” from the right side (Fig. 4a, pg. 8). -
Page 5: Maintenance
Note: Maximum charging current under discharges is 3.6A. Note: Expected battery life is 5 years, however it is recommended changing batteries in 4 years or less if needed. Fig. 2 - AL1024ULXB2 Board Configuration AC DELAY AL1024NK8QP Series Installation Guide - 5 -... -
Page 6: Led Diagnostics
NC, C, NO Battery reconnection is reported within 1 minute. Low battery threshold: approximately 21VDC (Fig. 2b, pg. 5). – BAT + Stand-by battery connections. Maximum charge current 3.6A (Fig. 2c, pg. 5). - 6 - AL1024NK8QP Series Installation Guide... - Page 7 Connection to [ + BAT –] terminals on power supply. R + INP2 – Factory connected to VR6. S + INP1 – Factory connected to AL1024ULXB2. T EOL OFF Internal FACP 2.2K ohm resistor ON/OFF switch. AL1024NK8QP Series Installation Guide - 7 -...
- Page 8 12AH Rechargeable batteries are the largest batteries that Tamper Switch can fit in this enclosure. (included) A UL listed external battery enclosure must be used if using To Access Control Panel or 40AH or 65AH batteries. UL Listed Reporting Device - 8 - AL1024NK8QP Series Installation Guide...
- Page 9 Network Setup: –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Please be sure to visit altronix.com for latest firmware and installation instructions. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– Altronix Dashboard USB Connection: The USB connection on the LINQ8PD(CB) is used for Network. When connected to a PC via the USB cable the LINQ8PD(CB) will receive power from the USB port allowing programming of the LINQ8PD(CB) prior to being connected to the power supply.
-
Page 10: Browser Setup
A dialog box will display “New network settings will take effect after the server is rebooted”. Click OK. Browser Setup: When not using the Altronix Dashboard USB connection for the initial Network setup the LINQ8PD(CB) needs to be connected to any DC power supply(ies) or AL1024ULXB2 power supply(ies) being monitored prior to programing. - Page 11 You have to reduce either stand-by current consumption or stand-by time in order to comply with requirement. To determine actual battery size please round line [J] to the nearest larger standard battery size (e.g. 3.5 AH = 4.0 AH). AL1024NK8QP Series Installation Guide - 11 -...
- Page 12 1.5” 4.615” (117.2mm) 4.615” (117.2mm) (38.1mm) (38.1mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty MEMBER IIAL1024NK8QP Series...
