Directechs DIRECTED DB3 Installation Manual page 11

Module
Conn./Pin Color
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
11 403.FORD6 3.24 2013 Ford Taurus (40-Bit)
©2022 VOXX•DEI LLC. All rights reserved.
Description
[1]
(-) Trunk Hatch Release/Power Liftgate Output
(DATA) TX
(DATA) RX
(-) Parking Light Output
Description
No Connection
No Connection
No Connection
No Connection
No Connection
(-) Hood Switch Input
No Connection
No Connection
No Connection
No Connection
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
Trunk Release Switch, black 6 pin plug, pin 6
Not Applicable
PATS Transceiver on ignition switch, black 4 pin plug, pin 3
PATS Transceiver on ignition switch, black 4 pin plug, pin 4
Must use a relay.
15A fuse to 12V
BCM under driver dash, gray 10 pin plug (E), pin 6
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color
- Brown/Yellow (except police)
Data Yellow/Orange
Data Violet/Gray
+ Yellow/Blue
(+/-) Wire Color
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
No Connection
No Connection
