Wampat W01M3141S Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Assembly Instructions
W01M3141S
Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the W01M3141S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wampat W01M3141S

Summary of Contents for Wampat W01M3141S

  • Page 1 Assembly Instructions W01M3141S Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
  • Page 4 This illustration shows how the CAM fastening system works. A × 26 B × 22 C × 22 D × 22 Esta ilustración muestra como funciona el sistema de fijación de leva. Cette illustration montre comment le système de fixation de la CAME fonctionne. H ×...
  • Page 5 A x 4 H x 6 ·Insert dowels (A) into panel (2). ·Attach panel (2) into panel (3). ·Screw parts (H) into panels (2,3). ３...
  • Page 6 B x 6 ·Screw parts (B) into panel (2).
  • Page 7 B x 2 ·Screw parts (B) into panel (6).
  • Page 8 A x 6 C x 6 ·Insert dowels (A) into panel (2). ·Attach panels(4,5,6) to panel (2). ·Insert and secure cam locks (C) to panels (4,5,6) to lock them with the panel (2).
  • Page 9 ·Slide part (11) into designated area.
  • Page 10 B x 6 ·Screw parts (B) into panel (12).
  • Page 11 A x 6 C x 6 ·Insert dowels (A) into panels (4,5,6). ·Attach panel(12) to panels (4,5,6). ·Insert and secure cam locks (C) to panels (4,5,6) to lock them with the panel (12).
  • Page 12 A x 2 C x 2 ·Insert dowels (A) into panel (7). ·Attach panel(7) to panel (6). ·Insert and secure cam locks (C) to panel (7) to lock it with the panel (6).
  • Page 13 B x 2 ·Screw parts (B) into panel (8).
  • Page 14 A x 2 C x 2 ·Insert dowels (A) into panel (8). ·Attach panel (8) to panel (7). ·Insert and secure cam locks (C) to panel (7) to lock it with the panel (8).
  • Page 15 E × 6 G × 6 ·Screw parts (F,G) into panels (2,4,6,12).
  • Page 16 J× 2 I × 6 K × 6 ·Attach parts (I) to panel (12) with parts (K). ·Knock parts (J) into panel (8).
  • Page 17 B x 6 ·Screw parts (B) into panel (1).
  • Page 18 A x 6 C x 6 ·Flip 180°and insert dowels (A) into panels (3,8). ·Attach panel(1) to panels (3,8). ·Insert and secure cam locks (C) to panels (3,8) to lock them with the panel (1).
  • Page 19 F x 4 E x 8 ·Attach parts (F) to panels (9,10) with screws (E).
  • Page 20 E x 16 ·Attch panels (9,10) to panel (12) with screws (E).
  • Page 21 L × 8 M × 1 N × 1 ·Attach part (M) to panels (4,9) with screws (L). ·Attach part (N) to panels (6,10) with screws (L).
  • Page 22 D × 22 Stick stickers (D) on cam locks (C).
  • Page 23 Please clean the surface before installation. Step 1: Keep the switch in the "off" Step 2: Plug USB cable into your TV Step 3: Tear tape behind the light strip and stick anywhere you want Note: 1. Light strip is non-waterproof. P ×...
  • Page 24 Adjust horizontal position Loosen the four screws "A" on hinges, two of them are usually in slotted holes and adjust up or down in the horizontal direction Finally, tighten the screws "A" back Adjust depth position Loosen the screw “B” on hinges and adjust door depth If the door can not be adjusted, please loosen the screw "C", then try it again...

  • Page 25: Final Assembly

    Final Assembly...
