- Page 1 Assembly Instructions W01F3092C Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
- Page 4 x 13 x 10 x 13 Screw GLUE Wooden dowel Cam bolt Cam lock Hinge Ø4x40mm x 24 Screw Handle bolt Handle Crash pad Shelf support Footpads Ø3.5x14mm 4x20mm x 12 x 17 x 12 Screw Sticker Plastic wedge Ø3x16mm Tipping restraint hardware kit (inside plastic bag) Tools Required...
- Page 5 ● The provided glue(G) is to secure wood dowels(A) in place . When first inserting dowels, locate the appropriate hole for the dowel , place a small amount of glue in the hole and insert the dowel . Wipe away excess glue immediately.
- Page 6 x 11 · Screw cam bolts (D) into panels (1,4).
- Page 7 · Insert and secure cam locks (C) to panels (2,3) to lock it.
- Page 8 · Insert and secure cam locks (C) to panels (2,3,6) to lock it.
- Page 9 · Carefully slide panels (9) into place along the back of the assembly.
- Page 10 · Attach panels (4) to Wooden leg (8). · Insert and secure screw (E) to Wooden leg (8) to lock it. · Stick stickers (P) on screw (E).
- Page 11 · Insert and secure cam locks (C) to panels (2,3) to lock it.
- Page 12 x 12 x 12 · Secure parts (N) to panels (1,2,3,4) using screws (O).
- Page 13 · Insert the shelf supports (H) at the desired level and place the adjustable shelves (5) onto the shelf supports.
- Page 14 · Attach part (F) to panels (7)with screws (G) correctly. · Attach part (I) to panels (7)with bolts (J) correctly.
- Page 15 · Stick stickers (P) on cam locks (C). x 13 x 16 · Attach part (7) to panel (2,3) with screws (G) correctly. · Stick part (M) on panels (7) correctly.
- Page 16 Adjust Height Adjust front and back Adjust Left and right...
- Page 17 WARNING Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
