- Page 1 Assembly Instructions W01D3187G/W01D3188O...
- Page 4 x 21 x 24 x 21 x 16 x 10 Wooden dowel Screw Screw Screw Cam lock Cam bolt Ø4x40mm Ø4x15mm Ø3x16mm Ø6x30mm Ø15x9.5mm Ø6x24mm x 24 Screw Screw Screw bolt Shelf support pin Door pivot Ø3x16mm Ø3x12mm Ø4x14mm M4x20mm bolt Wrench Handle...
- Page 5 Installation complete Installation complete · Screw cam bolts(A) into panel(8). · Insert dowels(C) into panels(4,5). · Attach panel(8) to panels(4,5). · Insert and secure cam locks(B) to panels(4,5) to lock it. ３...
- Page 6 · Screw cam bolts(A) into panels(2,3). · Attach part (S1) to panels (2,3) with screws (G).
- Page 7 · Attach part (14) to panel (6) with screws (E).
- Page 8 2 Person Task · Insert dowels(C) into panel(6). · Attach panels(2,3) to panel(6). · Insert and secure cam locks(B) to panel(6) to lock it. · Screws parts (W) into parts (14).
- Page 9 2 Person Task · Insert dowels (C) into panels (4,5). · Attach panels (4,5) to panel (6) with screws (D).
- Page 10 · Attach part (17) to panel (7) with parts (O) correctly.
- Page 11 ·Carefully slide panel (13) into place along the back of the assembly.
- Page 12 · Screw cam bolts(A) into panel(1). x 13 · Insert dowels(C) into panel(7). · Attach panel(7) to panel(1). · Insert and secure cam locks(B) to panel(7) to lock it.
- Page 13 2 Person Task · Insert dowels(C) into panels(2,3,4,5). · Attach panel(1) to panels(2,3,4,5). · Insert and secure cam locks(B) to panels(2,3,4,5) to lock it.
- Page 14 x 10 x 10 · Secure parts (T) to panels (1,2,3,6) using screws (F). · Attach panel (13) with screws (V) correctly.
- Page 15 · Attach parts (R) to panels (9,10) with screws (J) correctly. · Attach parts (S2) to panels (9,10) with screws (H) correctly. · Attach parts (Q) to panels (9,10) with bolts (K) correctly.
- Page 16 2 Person Task x 16 · Attach part (9) to panel (4) with screws (J) correctly. · Attach part (10) to panel (5) with screws (J) correctly.
- Page 17 · Attach part (15) to panel (16) with screws (Y) correctly. · Attach panel (16) to panels (4,5) using parts (L).
- Page 18 2 Person Task Step 2 Step 2 Step 1 · Attach parts (Q) to panels (11,12) with bolts (K) correctly. · Secure parts(M) to panels ( 6 ) . · Slide doors(11,12) into designated area.
- Page 19 2 Person Task · Stick stickers (U) on cam locks (B). x 12 Step 1 Step 2 · Put parts(N) into part(17) correctly. · Attach parts(N) to panels(11,12) with screws (E) correctly.
- Page 20 Please clean the surface before installation. Step 1: Keep the switch in the "off" Step 2: Plug USB cable into your TV or socket Step 3: Tear tape behind the light strip and stick anywhere you want Note: 1. Light strip is non-waterproof. 2.There are cutting marks on the light strip.
- Page 21 WARNING Serious or fatal injuries can occur from furniture tipping over. To prevent the furniture from tipping over we recommend that it is permanently fixed to the wall. Wall anchor and hardware are included with this product. Please make sure hardware is suitable for your walls before installing, as different wall materials may require different types of anchors.
