Black Electric Single Motor Desk Frame
Instruction Manual
SKU: DESK-V100EBY
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/desk-v100eby
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DESK-V100EBY and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo DESK-V100EBY

  • Page 1 Black Electric Single Motor Desk Frame Instruction Manual SKU: DESK-V100EBY Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/desk-v100eby GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury.
  • Page 3 ASSEMBLY STEPS STEP 1 Loosen the screws on Crossbar (C) using 5mm Allen Wrench (T-A) and extend. Assemble Crossbar (C) to Leg (A) and Motorized Leg (B) using M8x50 Screws (S-A) and 5mm Allen Wrench (T-A). STEP 2 Assemble Feet (D) to Leg (A) and Motorized Leg (B) using M6x35 Screws (S-C) and 5mm Allen Wrench (T-A).
  • Page 4 STEP 3 Mount Side Brackets (E) to the frame assembly using M8x12 Screws (S-B) and 5mm Allen Wrench (T-A). STEP 4 Hang Tray (F) over Crossbar (C).
  • Page 5 STEP 5 Loosen the screws on Crossbar (C) using 5mm Allen Wrench (T-A) and extend to fit your desktop. Once adjusted, retighten the screws. STEP 6 Mark and drill pilot holes to a depth of 3/8" (10mm) using a 1/8" (3mm) bit where Side Brackets (E) align on the desktop.
  • Page 6 STEP 7 Loosen the knob on Sync Rod (G) and extend the larger end onto the hex shaft on Motorized Leg (B). Tighten the nut onto the hex shaft using Wrench (T-B). Extend the hex shaft on Sync Rod (G) into Leg (A). Tighten the nut using Wrench (T-B). STEP 8 Use Control Panel (H) to mark and drill pilot holes to a depth of 3/8"...
  • Page 7 STEP 9 Insert Hooks (K) into Side Brackets (E). Place AC Adapted (I) in Tray (F). Organize cables using Cable Clips (S-E). STEP 10 Plug Power Cable (J) into an AC power outlet. The desk is now ready for use. Please refer to the Control Panel User Guide for operational instructions.
  • Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
