PRODUCT NAME: Taylor Media Tower
ITEM NUMBER: MQ131
ASSEMBLED DIMENSIONS : 82"H x 34"W x 17"D
LEVELERS: Tower is equipped with Rotary Levelers under each corner which are accessible from
INSIDE cabinet. 1. Insert screwdriver through hole in corner, adjust Leveler by turning clockwise/counter-
clockwise. 2. Cover hole with Wooden Plug (C)
1
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 11-17 -2021
Serious or fatal crushing injuries can occur from a furniture tip-over
Phillips Screwdriver, Flat Blade Screwdriver (levelers)
-Two person installation suggested.
Ltr.
Qty.
2
A
B
12
C
4
D
2
E
1
2
(C)
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
WARNING
Tip-Over Hazard
ANCHORING HARDWARE INCLUDED
Prevent tipping accidents. Anchor your furniture.
REQUIRED TOOLS:
Hardware/Components Included
Wall Anchoring
(Anti-tip) Kits
See page 3
Shelf Supports
Wooden Plugs
Upper Shelves
Lower (narrow) Shelf
MADE IN CHINA
