FEATURES

USB 2.0 interface
Jumper for temperature compensation mode enable
Jumper for power down mode enable
Measurement test points and coaxial connectors

EVALUATION KIT CONTENTS

ADA4571
magnetic stimulus:
Dipole magnet
Brushed or brushless dc motor with integrated control
electronics
Evaluation software CD-ROM (Windows® 7 32-bit and 64-bit
compatible GUI)

ADDITIONAL EQUIPMENT NEEDED

Customer supplied 6 V to 12 V bench supply
SDP interface board
USB cable (supplied with SDP interface board)
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Arrow.com.
Downloaded from
ADA4571
End of Shaft Evaluation Board

EVALUATION BOARD CONNECTION DIAGRAM

PC GUI INTERFACE
USB
Figure 1.
ADA4571
End of Shaft Evaluation System
Rev. 0 | Page 1 of 13
ADA4571R-EBZ User Guide

GENERAL DESCRIPTION

The end of shaft evaluation system is composed of a Windows
LabVIEW® GUI software, an
magnetic stimulus mounted on top of a brushless dc motor, a
daughter board with
ADA4571
interface and controller board, the SDP-S.
The motherboard features an on-board 5 V regulator, a
2-channel simultaneous sampling ADC and jumpers for
enabling the temperature compensation and power-down
modes within the ADA4571. The motherboard also features
test points and unpopulated coaxial connectors for the three
outputs of the device.
The daughter board features the
magnetic stimulus as well as test points for the three outputs of
the device.
The SDP board is used to control the ADC on the motherboard
and interface with the GUI.
6V TO 12V
SUPPLY
POWER
SUPPLY
EVALUATION
SDP CONTROL
SYSTEM
CARD
WITH MAGNETIC
STIMULUS
UG-739
ADA4571
motherboard, a
in its SOIC package, and a USB
ADA4571
mounted above the
