Icom IC-M802 Service Manual page 99

[PLL UNIT]
REF ORDER
NO. NO.
R5113 7030007210 S.RESISTOR
R5114 7030007210 S.RESISTOR
R5115 7030007210 S.RESISTOR
R5116 7030007210 S.RESISTOR
R5117 7030007210 S.RESISTOR
R5118 7030007230 S.RESISTOR
R5119 7030007230 S.RESISTOR
R5120 7030007230 S.RESISTOR
R5121 7030007230 S.RESISTOR
R5122 7030007230 S.RESISTOR
R5123 7030007230 S.RESISTOR
R5124 7030007220 S.RESISTOR
R5125 7030003320 S.RESISTOR
R5126 7030003800 S.RESISTOR
R5127 7030003380 S.RESISTOR
R5128 7030003320 S.RESISTOR
R5129 7030003380 S.RESISTOR
R5130 7030003460 S.RESISTOR
R5131 7030003400 S.RESISTOR
R5132 7030003490 S.RESISTOR
R5133 7030003640 S.RESISTOR
R5134 7030003640 S.RESISTOR
R5135 7030003800 S.RESISTOR
R5136 7030003680 S.RESISTOR
R5137 7030003440 S.RESISTOR
R5138 7030003440 S.RESISTOR
R5139 7030003440 S.RESISTOR
R5140 7030003640 S.RESISTOR
R5141 7030003640 S.RESISTOR
R5142 7030003640 S.RESISTOR
R5143 7030003640 S.RESISTOR
R5144 7030003640 S.RESISTOR
R5145 7030003640 S.RESISTOR
R5146 7030003430 S.RESISTOR
R5203 7030003320 S.RESISTOR
R5204 7030003600 S.RESISTOR
R5205 7030003560 S.RESISTOR
R5206 7030003360 S.RESISTOR
R5207 7030003280 S.RESISTOR
R5251 7030003400 S.RESISTOR
R5281 7030003400 S.RESISTOR
R5282 7030003320 S.RESISTOR
R5283 7030003480 S.RESISTOR
R5284 7030003520 S.RESISTOR
R5285 7030003570 S.RESISTOR
R5287 7030003320 S.RESISTOR
R5288 7030003460 S.RESISTOR
R5289 7030003510 S.RESISTOR
R5291 7030003470 S.RESISTOR
R5292 7030003540 S.RESISTOR
R5293 7030003360 S.RESISTOR
R5302 7030003340 S.RESISTOR
R5303 7030003680 S.RESISTOR
R5304 7030003680 S.RESISTOR
R5305 7030003340 S.RESISTOR
R5306 7030003320 S.RESISTOR
R5307 7030003690 S.RESISTOR
R5308 7030003320 S.RESISTOR
R5309 7030003430 S.RESISTOR
R5310 7030003430 S.RESISTOR
R5311 7030003430 S.RESISTOR
R5312 7030003400 S.RESISTOR
R5351 7030003570 S.RESISTOR
R5352 7030003400 S.RESISTOR
R5353 7030003440 S.RESISTOR
R5354 7030003400 S.RESISTOR
R5403 7030003450 S.RESISTOR
R5404 7030003440 S.RESISTOR
R5406 7030003680 S.RESISTOR
R5407 7030003440 S.RESISTOR
R5408 7030003440 S.RESISTOR
R5410 7030003440 S.RESISTOR
R5522 7030003370 S.RESISTOR
R5524 7030003320 S.RESISTOR
R5551 7030003320 S.RESISTOR
R5556 7030003560 S.RESISTOR
R5557 7030003560 S.RESISTOR
R5601 7030003520 S.RESISTOR
R5602 7030003320 S.RESISTOR
R5603 7030003440 S.RESISTOR
R5604 7030003650 S.RESISTOR
DESCRIPTION
ERA3YEB 102V
ERA3YEB 102V
ERA3YEB 102V
ERA3YEB 102V
ERA3YEB 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 202V
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 470 V (47 Ω)
[OTH]
ERJ3GEYJ 471 V (470 Ω)
[USA], [CAN]
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 123 V (12 kΩ) [OTH]
ERJ3GEYJ 101 V (100 Ω)
[OTH]
ERJ3GEYJ 152 V (1.5 kΩ) [OTH]
ERJ3GEYJ 392 V (3.9 kΩ) [OTH]
ERJ3GEYJ 182 V (1.8 kΩ) [OTH]
ERJ3GEYJ 682 V (6.8 kΩ) [OTH]
ERJ3GEYJ 221 V (220 Ω)
[OTH]
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 821 V (820 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 122 V (1.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 271 V (270 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
[PLL UNIT]
REF ORDER
NO. NO.
R5605 7030003320 S.RESISTOR
R5606 7030003380 S.RESISTOR
R5607 7030003520 S.RESISTOR
R5608 7030003520 S.RESISTOR
R5609 7030003320 S.RESISTOR
R5610 7030003360 S.RESISTOR
R5611 7030003250 S.RESISTOR
R5612 7030003380 S.RESISTOR
R5613 7030003650 S.RESISTOR
R5614 7030003350 S.RESISTOR
R5701 7030007220 S.RESISTOR
R5702 7030007230 S.RESISTOR
R5703 7030007230 S.RESISTOR
R5704 7030007230 S.RESISTOR
R5705 7030007230 S.RESISTOR
R5706 7030007230 S.RESISTOR
R5707 7030007230 S.RESISTOR
R5708 7030007210 S.RESISTOR
R5709 7030007210 S.RESISTOR
R5710 7030007210 S.RESISTOR
R5711 7030007220 S.RESISTOR
R5712 7030007220 S.RESISTOR
R5713 7030007220 S.RESISTOR
R5714 7030007220 S.RESISTOR
R5715 7030007230 S.RESISTOR
R5716 7030007220 S.RESISTOR
R5717 7030007220 S.RESISTOR
R5718 7030007200 S.RESISTOR
R5719 7030007200 S.RESISTOR
R5720 7030007200 S.RESISTOR
R5721 7030003800 S.RESISTOR
R5722 7030003320 S.RESISTOR
R5781 7030003410 S.RESISTOR
R5782 7030007860 S.RESISTOR
R5783 7030003410 S.RESISTOR
R5799 7030003440 S.RESISTOR
R5801 7030007220 S.RESISTOR
R5802 7030007230 S.RESISTOR
R5803 7030007230 S.RESISTOR
R5804 7030007230 S.RESISTOR
R5805 7030007230 S.RESISTOR
R5806 7030007230 S.RESISTOR
R5807 7030007230 S.RESISTOR
R5808 7030007210 S.RESISTOR
R5809 7030007210 S.RESISTOR
R5810 7030007210 S.RESISTOR
R5811 7030007220 S.RESISTOR
R5812 7030007220 S.RESISTOR
R5813 7030007220 S.RESISTOR
R5814 7030007220 S.RESISTOR
R5815 7030007220 S.RESISTOR
R5816 7030007220 S.RESISTOR
R5817 7030007220 S.RESISTOR
R5818 7030007200 S.RESISTOR
R5819 7030007200 S.RESISTOR
R5820 7030007200 S.RESISTOR
R5821 7030003800 S.RESISTOR
R5822 7030003320 S.RESISTOR
R5881 7030000220 S.RESISTOR
R5882 7030003440 S.RESISTOR
R5883 7030003450 S.RESISTOR
R5885 7030003370 S.RESISTOR
R5886 7030003440 S.RESISTOR
R5887 7030003450 S.RESISTOR
R5888 7030003280 S.RESISTOR
R5889 7030003450 S.RESISTOR
R5890 7030003410 S.RESISTOR
R5891 7030003400 S.RESISTOR
R5892 7030003260 S.RESISTOR
5 - 10
DESCRIPTION
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 221 V (220 Ω)
ERJ3GEYJ 270 V (27 Ω)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 181 V (180 Ω)
ERA3YED 202V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YED 102V
ERA3YEB 102V
ERA3YEB 102V
ERA3YEB 102V
ERA3YED 202V
ERA3YED 202V
ERA3YED 202V
ERA3YED 202V
ERA3YED 102V
ERA3YED 202V
ERA3YED 202V
ERA3YEB 202V
ERA3YEB 202V
ERA3YEB 202V
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 8R2V (8.2 Ω)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERA3YED 202V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YEB 102V [USA], [CAN]
ERA3YEB 102V [USA], [CAN]
ERA3YEB 102V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YEB 202V [USA], [CAN]
ERA3YEB 202V [USA], [CAN]
ERA3YEB 202V [USA], [CAN]
ERJ3GEYJ 105 V (1 MΩ)
[USA], [CAN]
ERJ3GEYJ 101 V (100 Ω)
[USA], [CAN]
MCR10EZHJ 47 Ω (470)
[USA], [CAN]
ERJ3GEYJ 102 V (1 kΩ)
[USA], [CAN]
ERJ3GEYJ 122 V (1.2 kΩ)
[USA], [CAN]
ERJ3GEYJ 271 V (270 Ω)
[USA], [CAN]
ERJ3GEYJ 102 V (1 kΩ)
[USA], [CAN]
ERJ3GEYJ 122 V (1.2 kΩ)
[USA], [CAN]
ERJ3GEYJ 470 V (47 Ω)
[USA], [CAN]
ERJ3GEYJ 122 V (1.2 kΩ)
[USA], [CAN]
ERJ3GEYJ 561 V (560 Ω)
[USA], [CAN]
ERJ3GEYJ 471 V (470 Ω)
[USA], [CAN]
ERJ3GEYJ 330 V (33 Ω)
[USA], [CAN]
S.=Surface mount
