Icom IC-M802 Service Manual page 107

RC-25
[FRONT UNIT]
REF ORDER
NO. NO.
W8001 8900009531 CABLE
W8005 8900008860 CABLE
[DISPLAY UNIT]
REF ORDER
NO. NO.
IC8201 1140010640 S.IC
IC8202 1110005770 S.IC
IC8250 1130005720 S.IC
IC8260 1130007350 S.IC
IC8270 1110001810 S.IC
IC8280 1110002700 S.IC
IC8290 1180001070 S.IC
IC8301 1110005580 S.IC
IC8310 1180001250 S.IC
Q8251 1590001650 S.TRANSISTOR XP4601 (TX)
Q8260 1590000680 S.TRANSISTOR DTC114EUA T106
Q8280 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q8281 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q8282 1590000680 S.TRANSISTOR DTC114EUA T106
Q8300 1540000440 S.TRANSISTOR 2SD1619-T-TD
Q8301 1540000440 S.TRANSISTOR 2SD1619-T-TD
Q8340 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q8341 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q8342 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q8343 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q8344 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q8345 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
D8201 1750000370 S.DIODE
D8203 1750000370 S.DIODE
D8204 1750000550 S.DIODE
D8205 1750000550 S.DIODE
D8250 1750000550 S.DIODE
D8280 1750000370 S.DIODE
D8701 1750000550 S.DIODE
X8211 6050010501 S.XTAL
L8201 6200001830 S.COIL
L8202 6200005010 S.COIL
L8203 6200005010 S.COIL
L8206 6200003950 S.COIL
L8270 6200003260 S.COIL
L8286 6200005010 S.COIL
L8290 6200003950 S.COIL
L8701 6200001830 S.COIL
R8201 7030003640 S.RESISTOR
R8202 7030003640 S.RESISTOR
R8203 7030003640 S.RESISTOR
R8204 7030003640 S.RESISTOR
R8205 7030003560 S.RESISTOR
R8206 7030003640 S.RESISTOR
R8207 7030003640 S.RESISTOR
R8208 7030003650 S.RESISTOR
R8209 7030003680 S.RESISTOR
R8210 7030003640 S.RESISTOR
R8211 7030003640 S.RESISTOR
R8212 7030003640 S.RESISTOR
R8213 7030003640 S.RESISTOR
R8214 7030003640 S.RESISTOR
R8215 7030003640 S.RESISTOR
R8216 7030003640 S.RESISTOR
R8218 7030003440 S.RESISTOR
R8219 7030003440 S.RESISTOR
R8221 7030003440 S.RESISTOR
R8222 7030003440 S.RESISTOR
DESCRIPTION
OPC-942A (P=1 N=10 L=170)
OPC-875 (N:20 L:70)
DESCRIPTION
HD64F2134AFA20 (SX-2429B)
S-80942CNMC-G9C-T2
TC7W04F (TE12L)
TC74HC4066AF
TA7368F (TP1)
NJM2904M-TE1
TA7805F (TE16L)
AN8010M-(E1)
TA7808F (TE16L)
DA221 TL
DA221 TL
1SS355 TE-17
1SS355 TE-17
1SS355 TE-17
DA221 TL
1SS355 TE-17
CR-636A (14.7456 MHz)
NL 322522T-100J
NL 252018T-100J
NL 252018T-100J
HF50ACC 322513-T
NL 322522T-101J
NL 252018T-100J
HF50ACC 322513-T
NL 322522T-100J
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
[DISPLAY UNIT]
REF ORDER
NO. NO.
R8223 7030003640 S.RESISTOR
R8224 7030003640 S.RESISTOR
R8225 7030003590 S.RESISTOR
R8226 7030003470 S.RESISTOR
R8227 7030003560 S.RESISTOR
R8229 7030003560 S.RESISTOR
R8230 7030003640 S.RESISTOR
R8231 7030003640 S.RESISTOR
R8232 7030003640 S.RESISTOR
R8233 7030003640 S.RESISTOR
R8234 7030003440 S.RESISTOR
R8235 7030003500 S.RESISTOR
R8236 7030003320 S.RESISTOR
R8237 7030003660 S.RESISTOR
R8239 7030003440 S.RESISTOR
R8240 7030003440 S.RESISTOR
R8241 7030003680 S.RESISTOR
R8243 7030003680 S.RESISTOR
R8246 7030003640 S.RESISTOR
R8247 7030003240 S.RESISTOR
R8250 7030003680 S.RESISTOR
R8251 7030003590 S.RESISTOR
R8252 7030003680 S.RESISTOR
R8253 7030003540 S.RESISTOR
R8254 7030003620 S.RESISTOR
R8255 7030003640 S.RESISTOR
R8260 7030003560 S.RESISTOR
R8263 7030003640 S.RESISTOR
R8270 7030003420 S.RESISTOR
R8274 7030003660 S.RESISTOR
R8275 7030003500 S.RESISTOR
R8276 7030003440 S.RESISTOR
R8278 7030003570 S.RESISTOR
R8279 7030003600 S.RESISTOR
R8280 7030003560 S.RESISTOR
R8281 7030003680 S.RESISTOR
R8282 7030003690 S.RESISTOR
R8283 7030003440 S.RESISTOR
R8284 7030003650 S.RESISTOR
R8285 7030003400 S.RESISTOR
R8287 7030003560 S.RESISTOR
R8288 7030003470 S.RESISTOR
R8289 7030003460 S.RESISTOR
R8290 7030006060 S.RESISTOR
R8291 7030003440 S.RESISTOR
R8300 7030003510 S.RESISTOR
R8301 7030006220 S.RESISTOR
R8302 7030003510 S.RESISTOR
R8303 7030006220 S.RESISTOR
R8340 7030003600 S.RESISTOR
R8341 7030003400 S.RESISTOR
R8342 7030003600 S.RESISTOR
R8343 7030003400 S.RESISTOR
R8344 7030003600 S.RESISTOR
R8345 7030003400 S.RESISTOR
R8346 7030003650 S.RESISTOR
R8347 7030003390 S.RESISTOR
R8348 7030003660 S.RESISTOR
R8349 7030003380 S.RESISTOR
R8350 7030003660 S.RESISTOR
R8351 7030003380 S.RESISTOR
R8352 7030003680 S.RESISTOR
R8373 7030003420 S.RESISTOR
R8701 7030003260 S.RESISTOR
R8702 7030003260 S.RESISTOR
R8703 7030003680 S.RESISTOR
R8704 7030003320 S.RESISTOR
R8705 7030003800 S.RESISTOR
R8706 7030003320 S.RESISTOR
R8707 7030003440 S.RESISTOR
R8708 7510001560 S.THERMISTOR NTCG16 4BH 102KT
C8201 4030011600 S.CERAMIC
C8202 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C8203 4030011600 S.CERAMIC
C8204 4030011600 S.CERAMIC
C8205 4030006900 S.CERAMIC
5 - 18
DESCRIPTION
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 220 V (22 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 182 V (1.8 kΩ)
ERJ3GEYJ 152 V (1.5 kΩ)
ERJ12YJ100U (10 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ12YJ470U (47 Ω)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ12YJ470U (47 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 330 V (33 Ω)
[USA], [OTH]
ERJ3GEYJ 330 V (33 Ω)
[USA], [OTH]
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 102 V (1 kΩ)
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 103K-T
S.=Surface mount
