SECTION 5

5-1 IC-M802

[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1110004080 S.IC
IC501 1110005460 S.IC
IC901 1110005460 S.IC
IC1001 1130006220 S.IC
IC1002 1110005450 S.IC
IC1051 1110005450 S.IC
IC1101 1110005450 S.IC
IC1201 1110005140 S.IC
IC1301 1160000130 S.IC
IC1302 1160000130 S.IC
IC1303 1160000130 S.IC
IC1501 1180000420 S.IC
IC1502 1180002180 S.IC
IC1551 1110001400 S.IC
IC1601 1110003090 IC
IC1602 1130006220 S.IC
IC1603 1110003300 S.IC
IC1701 1130006220 S.IC
IC1702 1110005450 S.IC
IC1703 1130006220 S.IC
IC2001 1130008230 S.IC
IC2701 1110005460 S.IC
IC2702 1110005450 S.IC
IC3101 1180000420 S.IC
IC3201 1130005720 S.IC
IC3301 1130011210 S.IC
1140009240 S.IC
IC3302 1110005770 S.IC
1130009110 S.IC
IC3303 1140010050 S.IC
1140010632 S.IC
IC3601 1130007700 S.IC
IC3602 1130007700 S.IC
IC3603 1130007700 S.IC
IC3604 1130007700 S.IC
IC3605 1130007700 S.IC
IC3606 1110003690 S.IC
Q51 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q201 1560000720 S.FET
Q202 1560000720 S.FET
Q203 1580000620 S.FET
Q401 1580000620 S.FET
Q501 1580000620 S.FET
Q601 1530003150 S.TRANSISTOR 2SC4673D-TD
Q701 1580000620 S.FET
Q702 1580000620 S.FET
Q703 1580000620 S.FET
Q801 1580000620 S.FET
Q1203 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q1204 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q1205 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q1206 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q1207 1510000770 S.TRANSISTOR 2SA1586-GR (TE85R)
Q1501 1540000440 S.TRANSISTOR 2SD1619-T-TD
Q1502 1540000440 S.TRANSISTOR 2SD1619-T-TD
Q1503 1590000680 S.TRANSISTOR DTC114EUA T106
Q1504 1590000680 S.TRANSISTOR DTC114EUA T106
Q1601 1590000680 S.TRANSISTOR DTC114EUA T106
Q1801 1540000440 S.TRANSISTOR 2SD1619-T-TD
Q2101 1590000680 S.TRANSISTOR DTC114EUA T106
Q2102 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
Q2301 1560000720 S.FET
Q2302 1560000720 S.FET
Q2401 1580000620 S.FET
Q2501 1580000620 S.FET
Q3001 1590000680 S.TRANSISTOR DTC114EUA T106
Q3004 1530002690 S.TRANSISTOR 2SC4116-GR (TE85R)
D51 1750000810 S.DIODE
D52 1750000810 S.DIODE
PARTS LIST
DESCRIPTION
µPC2709T-E3
TA4107F (TE12L)
TA4107F (TE12L)
TC4W53FU (TE12L)
TS522IDT
TS522IDT
TS522IDT
NJM3403AV-TE1
TD62783AF (TP1)
TD62783AF (TP1)
TD62783AF (TP1)
TA78L05F (TE12R)
TA78M08F (TE16L)
µPC1555G2-T1
LA4425A
TC4W53FU (TE12L)
M5282FP 70CD
TC4W53FU (TE12L)
TS522IDT
TC4W53FU (TE12L)
BU4053BCFV-E2
TA4107F (TE12L) [USA], [CAN]
TS522IDT [USA], [CAN]
TA78L05F (TE12R)
TC7W04F (TE12L)
CAT24WC64J-TE13 [OTH]
HN58X24128FPI [USA], [CAN]
S-80942CNMC-G9C-T2 [OTH], [CAN]
S-80942ANMP-DD6-T2 [USA]
M30620FCAFP [OTH]
M30624FGAFP D5 [USA], [CAN]
BU4094BCF-E2
BU4094BCF-E2
BU4094BCF-E2
BU4094BCF-E2
BU4094BCF-E2
M62354GP 75EC
2SK2171-4-TD
2SK2171-4-TD
3SK131-T2 MAS
3SK131-T2 MAS
3SK131-T2 MAS
3SK131-T2 MAS
3SK131-T2 MAS
3SK131-T2 MAS
3SK131-T2 MAS
[OTH]
[OTH]
[USA], [CAN]
[USA], [CAN]
2SK2171-4-TD [USA], [CAN]
2SK2171-4-TD [USA], [CAN]
3SK131-T2 MAS [USA], [CAN]
3SK131-T2 MAS [USA], [CAN]
UM9957F/TR
UM9957F/TR
[MAIN UNIT]
REF ORDER
NO. NO.
D53 1790001770 S.DIODE
D101 1790001770 S.DIODE
D102 1790001770 S.DIODE
D103 1790001770 S.DIODE
D104 1790001770 S.DIODE
D105 1790000620 S.DIODE
D106 1790001770 S.DIODE
D107 1790001770 S.DIODE
D108 1790001770 S.DIODE
D109 1790001770 S.DIODE
D110 1790000620 S.DIODE
D201 1790001770 S.DIODE
D301 1790001770 S.DIODE
D302 1750000430 S.DIODE
D303 1790001770 S.DIODE
D401 1790000620 S.DIODE
D402 1790000620 S.DIODE
D403 1790000620 S.DIODE
D404 1790000620 S.DIODE
D601 1730002280 S.ZENER
D602 1790001770 S.DIODE
D901 1790001770 S.DIODE
D1102 1790001240 S.DIODE
D1201 1790001240 S.DIODE
D1202 1790001250 S.DIODE
D1203 1790001250 S.DIODE
D1204 1790001250 S.DIODE
D1205 1790001250 S.DIODE
D1206 1790000620 S.DIODE
D1207 1790001250 S.DIODE
D1501 1790001670 S.DIODE
D1502 1790001670 S.DIODE
D1551 1730002320 S.ZENER
D1552 1790001670 S.DIODE
D1554 1730002280 S.ZENER
D1801 1790001250 S.DIODE
D2101 1790001240 S.DIODE
D2102 1790001250 S.DIODE
D2103 1750000810 S.DIODE
D2104 1750000810 S.DIODE
D2201 1790001770 S.DIODE
D2202 1790001770 S.DIODE
D2203 1790001770 S.DIODE
D2204 1790001770 S.DIODE
D2301 1750000430 S.DIODE
D3001 1790001670 S.DIODE
D3002 1790001670 S.DIODE
D3003 1790001670 S.DIODE
D3004 1790001250 S.DIODE
D3006 1790001670 S.DIODE
D3007 1790001670 S.DIODE
D3301 1790001250 S.DIODE
D3302 1790001250 S.DIODE
D3336 1790001250 S.DIODE
D3337 1790001250 S.DIODE
FI201 2010002600 XTAL
FI231 2010001880 MONOLITH
FI301 2010002470 XTAL
FI401 2020001960 CERAMIC
FI402 2020001330 CERAMIC
X3301 6050010501 S.XTAL
L1 6200002650 S.COIL
L2 6200002910 S.COIL
L3 6200002860 S.COIL
L51 6200002860 S.COIL
L52 6200009880 S.COIL
L53 6200004670 S.COIL
L54 6200002040 S.COIL
5 - 1
DESCRIPTION
MA80WK-(TX)
MA80WK-(TX)
MA80WK-(TX)
MA80WK-(TX)
MA80WK-(TX)
MA77 (TX)
MA80WK-(TX)
MA80WK-(TX)
MA80WK-(TX)
MA80WK-(TX)
MA77 (TX)
MA80WK-(TX)
MA80WK-(TX)
HSB88WSTR
MA80WK-(TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA77 (TX)
MA8091-M (TX)
MA80WK-(TX)
MA80WK-(TX)
MA2S728-(TX)
MA2S728-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA77 (TX)
MA2S111-(TX)
RB706F-40T106
RB706F-40T106
MA8051-M (TX)
RB706F-40T106
MA8091-M (TX)
MA2S111-(TX)
MA2S728-(TX) [USA], [CAN]
MA2S111-(TX) [USA], [CAN]
UM9957F/TR [USA], [CAN]
UM9957F/TR [USA], [CAN]
MA80WK-(TX) [USA], [CAN]
MA80WK-(TX) [USA], [CAN]
MA80WK-(TX) [USA], [CAN]
MA80WK-(TX) [USA], [CAN]
HSB88WSTR [USA], [CAN]
RB706F-40T106
RB706F-40T106
RB706F-40T106
MA2S111-(TX)
RB706F-40T106
RB706F-40T106
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
FL-345 (64.455 MHz)
FL-231 (10.700 MHz) [USA], [CAN]
FL-315 (64.45500 MHz)
CFWLB455KHFA-B0 (CFWM455H)
CFWLA455KHFA-B0 (CFWS455HT)
CR-636A (14.7456 MHz)
NL 252018T-R18J
NL 252018T-R27J
NL 252018T-4R7J
NL 252018T-4R7J
NL 252018T-820J
NL 252018T-3R9J
NL 252018T-101J
S.=Surface mount
