Icom IC-M802 Service Manual page 103

[FILTER UNIT]
REF ORDER
NO. NO.
Q7301 1590000680 S.TRANSISTOR DTC114EUA T106
D7271 1750000190 S.DIODE
D7272 1750000190 S.DIODE
D7301 1750000550 S.DIODE
L7031 6200002040 S.COIL
L7035 6200002040 S.COIL
L7036 6140002830 COIL
L7037 6140002950 COIL
L7038 6140002960 COIL
L7061 6200002040 S.COIL
L7065 6200002040 S.COIL
L7066 6140002900 COIL
L7067 6140002820 COIL
L7068 6140002830 COIL
L7091 6200002040 S.COIL
L7095 6200002040 S.COIL
L7096 6140002850 COIL
L7097 6140002820 COIL
L7098 6140002820 COIL
L7121 6200002040 S.COIL
L7125 6200002040 S.COIL
L7126 6140002840 COIL
L7127 6140002900 COIL
L7128 6140002900 COIL
L7151 6200005050 S.COIL
L7155 6200005050 S.COIL
L7156 6140002860 COIL
L7157 6140002840 COIL
L7158 6140002840 COIL
L7181 6200005050 S.COIL
L7182 6140002880 COIL
L7183 6140002870 COIL
L7184 6140002870 COIL
L7185 6200005050 S.COIL
L7211 6200005010 S.COIL
L7215 6200005010 S.COIL
L7216 6140002870 COIL
L7217 6140002870 COIL
L7218 6140002870 COIL
L7241 6200005010 S.COIL
L7244 6200005010 S.COIL
L7245 6140002890 COIL
L7246 6140002890 COIL
L7248 6140002890 COIL
L7271 6200002040 S.COIL
L7272 6140003490 COIL
L7273 6200002040 S.COIL
L7321 6140001460 COIL
L7331 6200002040 S.COIL
L7332 6200002040 S.COIL
R7271 7030003560 S.RESISTOR
R7272 7030003490 S.RESISTOR
R7273 7030003520 S.RESISTOR
R7274 7030008190 S.RESISTOR
R7275 7030003560 S.RESISTOR
R7276 7030003490 S.RESISTOR
R7277 7030003520 S.RESISTOR
R7301 7030003200 S.RESISTOR
R7314 7540000250 ABSORBER
R7315 7030010650 S.RESISTOR
C7031 4510005480 ELECTROLYTIC 50 MV 1 HC
C7032 4030011600 S.CERAMIC
C7033 4320000651 DIP MICA
C7034 4010006410 CERAMIC
C7035 4010006410 CERAMIC
C7036 4320000981 DIP MICA
C7037 4010005360 CERAMIC
C7038 4010005880 CERAMIC
C7039 4320000951 DIP MICA
C7041 4030011120 S.CERAMIC
C7042 4010005930 CERAMIC
C7043 4010005930 CERAMIC
C7044 4010005930 CERAMIC
C7045 4010005370 CERAMIC
DESCRIPTION
1SS322 (TE85R)
1SS322 (TE85R)
1SS355 TE-17
NL 252018T-101J
NL 252018T-101J
LR-236
LR-226
LR-227
NL 252018T-101J
NL 252018T-101J
LR-263
LR-235
LR-236
NL 252018T-101J
NL 252018T-101J
LR-238
LR-235
LR-235
NL 252018T-101J
NL 252018T-101J
LR-237
LR-263
LR-263
NL 252018T-330J
NL 252018T-330J
LR-241
LR-237
LR-237
NL 252018T-330J
LR-243
LR-242
LR-242
NL 252018T-330J
NL 252018T-100J
NL 252018T-100J
LR-242
LR-242
LR-242
NL 252018T-100J
NL 252018T-100J
LR-262
LR-262
LR-262
NL 252018T-101J
LR-391
NL 252018T-101J
LR-170
NL 252018T-101J
NL 252018T-101J
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ12YJ330U (33 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 100 V (10 Ω)
SA05C 401N
ERJ12YJ823U (82 kΩ)
C1608 JB 1E 104K-T
KD20C 102J5A
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
KD20C 222J5A
HM11SJ SL 301J 500V
HM95SJ SL 271J 500V
KD20C 272J5A
GRM31M2C2H100JV01L
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM11SJ SL 331J 500V
[FILTER UNIT]
REF ORDER
NO. NO.
C7046 4030011600 S.CERAMIC
C7049 4010005850 CERAMIC
C7061 4510005480 ELECTROLYTIC 50 MV 1 HC
C7062 4030011600 S.CERAMIC
C7063 4030011730 S.CERAMIC
C7064 4010006410 CERAMIC
C7065 4010006410 CERAMIC
C7066 4010005370 CERAMIC
C7067 4010005880 CERAMIC
C7068 4010005880 CERAMIC
C7069 4010005880 CERAMIC
C7070 4030011730 S.CERAMIC
C7071 4010006410 CERAMIC
C7072 4010006410 CERAMIC
C7073 4010006410 CERAMIC
C7074 4010006410 CERAMIC
C7075 4010005370 CERAMIC
C7076 4010005370 CERAMIC
C7077 4010005370 CERAMIC
C7078 4010005930 CERAMIC
C7079 4010006410 CERAMIC
C7080 4030012480 S.CERAMIC
C7081 4030012480 S.CERAMIC
C7082 4010005930 CERAMIC
C7083 4010005930 CERAMIC
C7084 4030011550 S.CERAMIC
C7085 4030011600 S.CERAMIC
C7086 4030011120 S.CERAMIC
C7087 4030012480 S.CERAMIC
C7091 4510005480 ELECTROLYTIC 50 MV 1 HC
C7092 4030006880 S.CERAMIC
C7094 4010005370 CERAMIC
C7095 4010005930 CERAMIC
C7096 4010005930 CERAMIC
C7098 4010005370 CERAMIC
C7099 4010006410 CERAMIC
C7100 4030011730 S.CERAMIC
C7101 4010005360 CERAMIC
C7102 4030006880 S.CERAMIC
C7105 4010006410 CERAMIC
C7106 4010005830 CERAMIC
C7108 4010005370 CERAMIC
C7121 4510005480 ELECTROLYTIC 50 MV 1 HC
C7122 4030006880 S.CERAMIC
C7124 4030012480 S.CERAMIC
C7125 4010005930 CERAMIC
C7126 4030011120 S.CERAMIC
C7127 4030012480 S.CERAMIC
C7128 4010005880 CERAMIC
C7129 4010005360 CERAMIC
C7130 4030011510 S.CERAMIC
C7131 4030011070 S.CERAMIC
C7132 4010005360 CERAMIC
C7133 4030006880 S.CERAMIC
C7136 4010005850 CERAMIC
C7137 4030011730 S.CERAMIC
C7151 4510005480 ELECTROLYTIC 50 MV 1 HC
C7152 4030006880 S.CERAMIC
C7153 4030014460 S.CERAMIC
C7154 4010005930 CERAMIC
C7155 4030012480 S.CERAMIC
C7156 4030011120 S.CERAMIC
C7157 4010005930 CERAMIC
C7158 4030014460 S.CERAMIC
C7160 4030006880 S.CERAMIC
C7163 4010005850 CERAMIC
C7164 4030014460 S.CERAMIC
C7181 4510005480 ELECTROLYTIC 50 MV 1 HC
C7182 4030006880 S.CERAMIC
C7183 4030012480 S.CERAMIC
C7184 4030012480 S.CERAMIC
C7185 4010005880 CERAMIC
C7186 4030011510 S.CERAMIC
C7187 4010005370 CERAMIC
C7188 4030011180 S.CERAMIC
C7190 4030006880 S.CERAMIC
C7193 4010005850 CERAMIC
C7211 4510005480 ELECTROLYTIC 50 MV 1 HC
C7212 4030006880 S.CERAMIC
C7214 4030011240 S.CERAMIC
C7216 4030011190 S.CERAMIC
C7217 4030012480 S.CERAMIC
5 - 14
DESCRIPTION
C1608 JB 1E 104K-T
HM95SJ SL 181J 500V
C1608 JB 1E 104K-T
GRM31M2C2H101JV01L
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM11SJ SL 331J 500V
HM95SJ SL 271J 500V
HM95SJ SL 271J 500V
HM95SJ SL 271J 500V
GRM31M2C2H101JV01L
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM13SJ SL 471J 500V
HM11SJ SL 331J 500V
HM11SJ SL 331J 500V
HM11SJ SL 331J 500V
HM11SJ SL 391J 500V
HM13SJ SL 471J 500V
GRM31M2C2H121JV01L
GRM31M2C2H121JV01L
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
GRM31M2C2H680JV01L
C1608 JB 1E 104K-T
GRM31M2C2H100JV01L
GRM31M2C2H121JV01L
C1608 JB 1H 472K-T
HM11SJ SL 331J 500V
HM11SJ SL 391J 500V
HM11SJ SL 391J 500V
HM11SJ SL 331J 500V
HM13SJ SL 471J 500V
GRM31M2C2H101JV01L
HM11SJ SL 301J 500V
C1608 JB 1H 472K-T
HM13SJ SL 471J 500V
HM74SJ SL 151J 500V
HM11SJ SL 331J 500V
C1608 JB 1H 472K-T
GRM31M2C2H121JV01L
HM11SJ SL 391J 500V
GRM31M2C2H100JV01L
GRM31M2C2H121JV01L
HM95SJ SL 271J 500V
HM11SJ SL 301J 500V
GRM31M2C2H560JV01L
GRM31M2C2H5R0CY21L
HM11SJ SL 301J 500V
C1608 JB 1H 472K-T
HM95SJ SL 181J 500V
GRM31M2C2H101JV01L
C1608 JB 1H 472K-T
GRM31M2C2H820JV01L
HM11SJ SL 391J 500V
GRM31M2C2H121JV01L
GRM31M2C2H100JV01L
HM11SJ SL 391J 500V
GRM31M2C2H820JV01L
C1608 JB 1H 472K-T
HM95SJ SL 181J 500V
GRM31M2C2H820JV01L
C1608 JB 1H 472K-T
GRM31M2C2H121JV01L
GRM31M2C2H121JV01L
HM95SJ SL 271J 500V
GRM31M2C2H560JV01L
HM11SJ SL 331J 500V
GRM31M2C2H220JV01L
C1608 JB 1H 472K-T
HM95SJ SL 181J 500V
C1608 JB 1H 472K-T
GRM31M2C2H470JV01L
GRM31M2C2H270JV01L
GRM31M2C2H121JV01L
S.=Surface mount
