[VR UNIT]
REF ORDER
NO. NO.
R8901 7210002360 VARIABLE
EP8901 0910054742 PCB
[CONNECT UNIT]
REF ORDER
NO. NO.
L8220 6200001830 S.COIL
L8221 6200001830 S.COIL
R8241 7030003830 S.RESISTOR
R8242 7030003840 S.RESISTOR
R8243 7030003640 S.RESISTOR
R8244 7030003640 S.RESISTOR
R8245 7030003640 S.RESISTOR
R8246 7030003830 S.RESISTOR
C8230 4030011600 S.CERAMIC
C8231 4030011600 S.CERAMIC
C8232 4550006450 S.TANTALUM
C8233 4550006450 S.TANTALUM
C8234 4550006450 S.TANTALUM
C8235 4550006450 S.TANTALUM
C8236 4550006450 S.TANTALUM
C8237 4030011600 S.CERAMIC
J8220 6510022540 S.CONNECTOR 20FMN-BMTTR-A-TBT
DS8220 5030002320 LCD
EP8220 0910054783 PCB
DESCRIPTION
TP96N97-15F-10KB-1301
B 5730B
DESCRIPTION
NL 322522T-100J
NL 322522T-100J
ERJ3GEYJ 185 V (1.8 MΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 185 V (1.8 MΩ)
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
ECST1EY105R
ECST1EY105R
ECST1EY105R
ECST1EY105R
ECST1EY105R
C1608 JB 1E 104K-T
M802 LCD ASSEMBLY C
B 5751C
HM-135
[MAIN UNIT]
REF ORDER
NO. NO.
R1 7010006890 RESISTOR
R2 7010006910 RESISTOR
R3 7010006880 RESISTOR
R4 7010006900 RESISTOR
C1 4010008030 CERAMIC
MC1 7700002120 MICROPHONE KUC2123-030245
S1 2260002340 SWITCH
S2 2260002340 SWITCH
S3 2260002340 SWITCH
W1 9018490010 WIRE
W2 9018490010 WIRE
EP1 0910051480 PCB
EP2 9018230010 TUBE

[SW BOARD]

REF ORDER
NO. NO.
S1 2260002330 SWITCH
EP1 0910051490 PCB
SP-24
[CHASSIS ]
REF ORDER
NO. NO.
SP1 2510001170 SPEAKER
W1 8900011090 CABLE
EP1 8930006760 M.OTHER
5 - 20
DESCRIPTION
R20J 12 K Ω
R20J 33 K Ω
R20J 6.8K Ω
R20J 15 K Ω
DD104 B 471K 50V
SKHHAM024A
SKHHAM024A
SKHHAM024A
71/98/010/X98/X98
71/98/010/X98/X98
B 5324
IRRAX D=0.7 L=4MM
DESCRIPTION
SKHHLP014A
B 5325
DESCRIPTION
077P040P
OPC-1104
SR-2P-4
S.=Surface mount
