Icom IC-M802 Service Manual page 106

[DSP UNIT]
REF ORDER
NO. NO.
C54 4030006900 S.CERAMIC
C101 4030011600 S.CERAMIC
C102 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C103 4030011600 S.CERAMIC
C104 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C154 4030011600 S.CERAMIC
C155 4030011600 S.CERAMIC
C156 4030011600 S.CERAMIC
C157 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C158 4550006080 S.TANTALUM
C161 4550006620 S.TANTALUM
C162 4030011600 S.CERAMIC
C163 4030011600 S.CERAMIC
C164 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C171 4030011600 S.CERAMIC
C172 4030011600 S.CERAMIC
C173 4030011600 S.CERAMIC
C174 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C175 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C201 4030011600 S.CERAMIC
C202 4030011600 S.CERAMIC
C203 4030011600 S.CERAMIC
C301 4030006880 S.CERAMIC
C302 4030006880 S.CERAMIC
C303 4030011600 S.CERAMIC
C304 4030006880 S.CERAMIC
C305 4030011600 S.CERAMIC
C306 4030011600 S.CERAMIC
C307 4030011600 S.CERAMIC
C308 4030011600 S.CERAMIC
C309 4030006880 S.CERAMIC
C311 4030006880 S.CERAMIC
C312 4030011600 S.CERAMIC
C313 4030011600 S.CERAMIC
C314 4030006880 S.CERAMIC
C315 4030011600 S.CERAMIC
C316 4030006880 S.CERAMIC
C317 4030011600 S.CERAMIC
C318 4030006880 S.CERAMIC
C319 4030006880 S.CERAMIC
C320 4030011600 S.CERAMIC
C321 4030011600 S.CERAMIC
C322 4030006880 S.CERAMIC
C323 4030011600 S.CERAMIC
C324 4030006880 S.CERAMIC
C325 4030006880 S.CERAMIC
C401 4030006880 S.CERAMIC
C403 4030006880 S.CERAMIC
C404 4030006880 S.CERAMIC
C405 4030006880 S.CERAMIC
C406 4030006880 S.CERAMIC
C407 4030006860 S.CERAMIC
C408 4030006860 S.CERAMIC
C504 4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C505 4030011600 S.CERAMIC
C506 4550006620 S.TANTALUM
C507 4030011600 S.CERAMIC
C508 4030011600 S.CERAMIC
C509 4030011600 S.CERAMIC
C510 4550006620 S.TANTALUM
C511 4030007050 S.CERAMIC
C601 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C602 4030009980 S.CERAMIC
C603 4030011600 S.CERAMIC
C604 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C605 4030011600 S.CERAMIC
C606 4510005830 S.ELECTROLYTIC ECEV1HAN010R
C651 4030009980 S.CERAMIC
C652 4030011600 S.CERAMIC
C653 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C654 4030011600 S.CERAMIC
C655 4510005830 S.ELECTROLYTIC ECEV1HAN010R
C701 4030011280 S.CERAMIC
C702 4030007130 S.CERAMIC
C703 4030011600 S.CERAMIC
C704 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C705 4030007130 S.CERAMIC
C706 4030011600 S.CERAMIC
C707 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C708 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C751 4030011280 S.CERAMIC
C752 4030007130 S.CERAMIC
DESCRIPTION
C1608 JB 1H 103K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
TEMSVB2 1C 106M-8L
ECST0JY226R
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
ECST0JY226R
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
ECST0JY226R
C1608 CH 1H 220J-T
C1608 JB 1H 152K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 152K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 CH 1H 271J-T
C1608 CH 1H 101J-T
C1608 JB 1E 104K-T
C1608 CH 1H 101J-T
C1608 JB 1E 104K-T
C1608 CH 1H 271J-T
C1608 CH 1H 101J-T
[DSP UNIT]
REF ORDER
NO. NO.
C755 4030007130 S.CERAMIC
C756 4030011600 S.CERAMIC
C757 4510006220 S.ELECTROLYTIC ECEV1CA101UP
C758 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C801 4030006880 S.CERAMIC
C802 4030006860 S.CERAMIC
C901 4030006860 S.CERAMIC
J901 6910013900 CONNECTOR
J902 6910012460 CONNECTOR
W1 7030003860 S.JUMPER
W2 7030008240 S.JUMPER
W3 7030003860 S.JUMPER
W4 7030008240 S.JUMPER
W5 7030003860 S.JUMPER
W151 7030008240 S.JUMPER
W152 7030003860 S.JUMPER
W171 7030008240 S.JUMPER
W201 7030003860 S.JUMPER
W202 7030003860 S.JUMPER
W203 7030003860 S.JUMPER
W302 7030003860 S.JUMPER
W303 7030003860 S.JUMPER
W308 7030003860 S.JUMPER
W309 7030003860 S.JUMPER
W310 7030003860 S.JUMPER
W311 7030003860 S.JUMPER
W312 7030003860 S.JUMPER
W501 7030003860 S.JUMPER
W502 7030003860 S.JUMPER
W503 7030003860 S.JUMPER
W504 7030003860 S.JUMPER
W505 7030008240 S.JUMPER
W901 7030003860 S.JUMPER
W902 7030008240 S.JUMPER
W903 7030003860 S.JUMPER
W904 7030003860 S.JUMPER
W951 7030003860 S.JUMPER
W952 7030003860 S.JUMPER
EP1 0910054518 PCB
EP2 6910012350 S.BEAD
5 - 17
DESCRIPTION
C1608 CH 1H 101J-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
IMSA-9180S-22A
IMSA-9180S-30A
ERJ3GE JPW V
ERJ12YJ0R00U
ERJ3GE JPW V
ERJ12YJ0R00U
ERJ3GE JPW V
ERJ12YJ0R00U
ERJ3GE JPW V
ERJ12YJ0R00U
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V
ERJ12YJ0R00U
ERJ3GE JPW V
ERJ12YJ0R00U
ERJ3GE JPW V
ERJ3GE JPW V
ERJ3GE JPW V [OTH]
ERJ3GE JPW V
B 5666H
MMZ1608Y 102BT
S.=Surface mount
