Icom IC-M802 Service Manual page 100

[PLL UNIT]
REF ORDER
NO. NO.
R5901 7030007220 S.RESISTOR
R5902 7030007230 S.RESISTOR
R5903 7030007230 S.RESISTOR
R5904 7030007230 S.RESISTOR
R5905 7030007230 S.RESISTOR
R5906 7030007230 S.RESISTOR
R5907 7030007230 S.RESISTOR
R5908 7030007210 S.RESISTOR
R5909 7030007210 S.RESISTOR
R5910 7030007210 S.RESISTOR
R5911 7030007220 S.RESISTOR
R5912 7030007220 S.RESISTOR
R5913 7030007220 S.RESISTOR
R5914 7030007220 S.RESISTOR
R5915 7030007220 S.RESISTOR
R5916 7030007220 S.RESISTOR
R5917 7030007220 S.RESISTOR
R5918 7030007200 S.RESISTOR
R5919 7030007200 S.RESISTOR
R5920 7030007200 S.RESISTOR
R5921 7030003800 S.RESISTOR
R5922 7030003320 S.RESISTOR
R5982 7030003440 S.RESISTOR
C5021 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C5022 4030011600 S.CERAMIC
C5023 4030011600 S.CERAMIC
C5024 4510007510 S.ELECTOR
C5031 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C5032 4030011600 S.CERAMIC
C5033 4030011600 S.CERAMIC
C5034 4510007510 S.ELECTOR
C5051 4030011600 S.CERAMIC
C5052 4030011600 S.CERAMIC
C5053 4030011600 S.CERAMIC
C5055 4030011600 S.CERAMIC
C5081 4030006880 S.CERAMIC
C5082 4030006880 S.CERAMIC
C5083 4030006900 S.CERAMIC
C5084 4030006900 S.CERAMIC
C5085 4030008680 S.CERAMIC
C5086 4030008680 S.CERAMIC
C5087 4030008680 S.CERAMIC
C5088 4030008680 S.CERAMIC
C5089 4030006900 S.CERAMIC
C5090 4030008680 S.CERAMIC
C5091 4030006900 S.CERAMIC
C5092 4030006880 S.CERAMIC
C5101 4030007060 S.CERAMIC
C5102 4030007010 S.CERAMIC
C5103 4030006960 S.CERAMIC
C5104 4030006880 S.CERAMIC
C5105 4030006860 S.CERAMIC
C5106 4030006880 S.CERAMIC
C5107 4030006880 S.CERAMIC
C5108 4030006880 S.CERAMIC
C5110 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C5111 4030006880 S.CERAMIC
C5112 4030007090 S.CERAMIC
C5113 4030006880 S.CERAMIC
C5115 4030006880 S.CERAMIC
C5116 4510004640 S.ELECTROLYTIC ECEV1CA470SP
C5117 4030006880 S.CERAMIC
C5118 4030006880 S.CERAMIC
C5120 4030006880 S.CERAMIC
C5121 4030006880 S.CERAMIC
C5122 4030006880 S.CERAMIC
C5123 4030006880 S.CERAMIC
C5124 4030006880 S.CERAMIC
C5125 4030011600 S.CERAMIC
C5126 4030011600 S.CERAMIC
C5201 4030006860 S.CERAMIC
C5202 4030006860 S.CERAMIC
C5203 4030006880 S.CERAMIC
C5204 4030006880 S.CERAMIC
C5205 4030007030 S.CERAMIC
C5206 4030006910 S.CERAMIC
C5207 4030007030 S.CERAMIC
DESCRIPTION
ERA3YED 202V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YED 102V [USA], [CAN]
ERA3YEB 102V [USA], [CAN]
ERA3YEB 102V [USA], [CAN]
ERA3YEB 102V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YED 202V [USA], [CAN]
ERA3YEB 202V [USA], [CAN]
ERA3YEB 202V [USA], [CAN]
ERA3YEB 202V [USA], [CAN]
ERJ3GEYJ 105 V (1 MΩ)
[USA], [CAN]
ERJ3GEYJ 101 V (100 Ω)
[USA], [CAN]
ERJ3GEYJ 102 V (1 kΩ)
[USA], [CAN]
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
ECEV1AA470WR
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
ECEV1AA470WR
C1608 JB 1E 104K-T [USA], [CAN]
C1608 JB 1E 104K-T [USA], [CAN]
C1608 JB 1E 104K-T [USA], [CAN]
C1608 JB 1E 104K-T [USA], [CAN]
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T [USA], [CAN]
C1608 JB 1H 103K-T
C1608 JB 1H 103K-T
C2012 JF 1C 105Z-T
C2012 JF 1C 105Z-T
C2012 JF 1C 105Z-T
C2012 JF 1C 105Z-T
C1608 JB 1H 103K-T
C2012 JF 1C 105Z-T
C1608 JB 1H 103K-T
C1608 JB 1H 472K-T
C1608 CH 1H 270J-T
C1608 CH 1H 100D-T
C1608 CH 1H 050C-T
C1608 JB 1H 472K-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 470J-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 150J-T
C1608 CH 1H 0R5C-T
C1608 CH 1H 150J-T
[PLL UNIT]
REF ORDER
NO. NO.
C5251 4030007130 S.CERAMIC
C5253 4030006880 S.CERAMIC
C5254 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C5281 4030006880 S.CERAMIC
C5282 4030006860 S.CERAMIC
C5283 4030006880 S.CERAMIC
C5284 4030006880 S.CERAMIC
C5285 4510005600 S.ELECTROLYTIC ECEV1CS100SR
C5287 4030006880 S.CERAMIC
C5288 4030007130 S.CERAMIC
C5289 4030007130 S.CERAMIC
C5290 4030008230 S.CERAMIC
C5291 4030006880 S.CERAMIC
C5292 4030000840 S.CERAMIC
C5293 4030006880 S.CERAMIC
C5294 4610001850 S.TRIMMER
C5295 4030006860 S.CERAMIC
C5301 4550000730 S.TANTALUM
C5302 4030006880 S.CERAMIC
C5303 4030009650 S.CERAMIC
C5304 4030011570 S.CERAMIC
C5305 4610001850 S.TRIMMER
C5306 4030007150 S.CERAMIC
C5307 4030007150 S.CERAMIC
C5308 4030007150 S.CERAMIC
C5309 4030006880 S.CERAMIC
C5310 4030007010 S.CERAMIC
C5311 4030006880 S.CERAMIC
C5312 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C5313 4030006880 S.CERAMIC
C5314 4030006880 S.CERAMIC
C5315 4030006880 S.CERAMIC
C5351 4030006880 S.CERAMIC
C5352 4030006880 S.CERAMIC
C5353 4030006880 S.CERAMIC
C5354 4030010000 S.CERAMIC
C5355 4030006960 S.CERAMIC
C5356 4030010000 S.CERAMIC
C5357 4030006880 S.CERAMIC
C5401 4030011600 S.CERAMIC
C5402 4030006860 S.CERAMIC
C5403 4030006900 S.CERAMIC
C5404 4030006880 S.CERAMIC
C5408 4550005980 S.TANTALUM
C5521 4610001830 S.TRIMMER
C5522 4030007130 S.CERAMIC
C5523 4030007010 S.CERAMIC
C5524 4030006880 S.CERAMIC
C5525 4030006870 S.CERAMIC
C5526 4030009510 S.CERAMIC
C5528 4030006860 S.CERAMIC
C5529 4030011340 S.CERAMIC
C5551 4550005980 S.TANTALUM
C5552 4550003250 S.TANTALUM
C5556 4030006860 S.CERAMIC
C5557 4030011600 S.CERAMIC
C5558 4510004590 ELECTROLYTIC 16 MV 470 HC
C5560 4510005430 S.ELECTROLYTIC ECEV0JA220SR
C5561 4030011340 S.CERAMIC
C5601 4030006880 S.CERAMIC
C5602 4030006860 S.CERAMIC
C5603 4030006880 S.CERAMIC
C5604 4030006880 S.CERAMIC
C5605 4030006880 S.CERAMIC
C5606 4030006860 S.CERAMIC
C5607 4030006880 S.CERAMIC
C5608 4030006880 S.CERAMIC
C5609 4030007090 S.CERAMIC
C5610 4030011280 S.CERAMIC
C5611 4030007090 S.CERAMIC
C5612 4030007060 S.CERAMIC
C5613 4030007020 S.CERAMIC
C5614 4030007060 S.CERAMIC
C5615 4030006980 S.CERAMIC
C5616 4030007040 S.CERAMIC
C5617 4030006860 S.CERAMIC
C5618 4030006880 S.CERAMIC
C5619 4030006930 S.CERAMIC
C5701 4030006880 S.CERAMIC
C5702 4030006880 S.CERAMIC
C5703 4030006880 S.CERAMIC
C5704 4030006880 S.CERAMIC
5 - 11
DESCRIPTION
C1608 CH 1H 101J-T [USA], [CAN]
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T [OTH]
[OTH]
C1608 JB 1H 472K-T [OTH]
C1608 CH 1H 101J-T [OTH]
C1608 CH 1H 101J-T [OTH]
C1608 UJ 1H 080D-T [OTH]
C1608 JB 1H 472K-T [OTH]
GRM2163C1H3R0CD01D [OTH]
C1608 JB 1H 472K-T [OTH]
TZB4R200AB10R00 [OTH]
C1608 JB 1H 102K-T [OTH]
TESVA 0J 225M1-8L
C1608 JB 1H 472K-T
C1608 CH 1H 240J-T
CM105 CH 101G 50AT
TZB4R200AB10R00
C1608 CH 1H 151J-T
C1608 CH 1H 151J-T
C1608 CH 1H 151J-T
C1608 JB 1H 472K-T
C1608 CH 1H 100D-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 510J-T
C1608 CH 1H 050C-T
C1608 CH 1H 510J-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 103K-T
C1608 JB 1H 472K-T
TEMSVA 1A 475M-8L
TZB4S100AB10R00
C1608 CH 1H 101J-T
C1608 CH 1H 100D-T
C1608 JB 1H 472K-T
C1608 JB 1H 222K-T
C1608 CH 1H 010B-T
C1608 JB 1H 102K-T
C1608 CH 1H 471J-T
TEMSVA 1A 475M-8L
TEMSVA 1V 474M-8L
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C1608 CH 1H 471J-T
C1608 JB 1H 472K-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 470J-T
C1608 CH 1H 271J-T
C1608 CH 1H 470J-T
C1608 CH 1H 270J-T
C1608 CH 1H 120J-T
C1608 CH 1H 270J-T
C1608 CH 1H 070D-T
C1608 CH 1H 180J-T
C1608 JB 1H 102K-T
C1608 JB 1H 472K-T
C1608 CH 1H 020C-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
S.=Surface mount
