1 |
028-0324-02_LIT-VZ7656F_B-E01_EN
VZ7656F1000B
BACnet™ MS-TP RTU Terminal Equipment
Controller with Modulating Heat
Installation Guide
For Commerci al Zoning Systems
October 2019 / 028 - 0324 - 02
NOTICE
www.viconics.com
2
3
5
6
8
9
10
12
14
19
27
28
October 2019
Advertisement
Table of Contents
Related Manuals for Viconics BACnet VZ7656F1000B
Summary of Contents for Viconics BACnet VZ7656F1000B
-
Page 1: Table Of Contents
This document contains information on active and retired products. The latter are no longer sold by Viconics Technologies or its partners. For additional information on 7000 Series Room Controllers and a list of replacement part numbers, please visit http://www.viconics.com/. -
Page 2: Safety Information
A qualified person is one who has skills and knowledge related to the construction, installation, and operation of electrical equipment and has received safety training to recognize and avoid the hazards involved. 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... -
Page 3: Before You Begin
• Avoid touching exposed conductors and components leads with skin or clothing. For additional information about anticipated transmission delays or failures of the link, refer to NEMA ICS 1.1 (latest edition), Safety Guidelines for the Application, Installation and Maintenance of Solid State Control or its equivalent. 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... - Page 4 • Do not drop or crush the Room Controller, or allow it to come into contact with liquids. • Do not use a damaged device (such as one with a cracked screen). Failure to comply with these recommendations will result in damage to the unit and void the manufacturer’s warranty. 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
-
Page 5: Installation
Insert screws in mounting holes on each side of the base (fig. 2). Gently swing back the circuit board on the base and push on it until the tabs lock it. Strip each wire 1/4 inch from end. 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... -
Page 6: Theory Of Operation
HEORY OF PERATION The VZ7656 series uses a Viconics proprietary adaptive logic algorithm to control the space temperature. This algorithm controls the heating and or air conditioning system to minimize overshoot while still providing comfort. It provides exceptional accuracy due to its unique PI time proportioning control algorithm, which virtually eliminates temperature offset associated with traditional, differential-based on/off thermostats. - Page 7 Easy configuration without using any special software or additional tools. • Can be used as stand-alone or with BACnet™ MS-TP supervision controller for • monitoring purposed. Truly scalable in terms of supported number of zones and RTU units. • 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
-
Page 8: Bacnet System Overview
YSTEM VERVIEW Viconics VZ7260x5x00B Zone controllers are used in conjunction with the VZ7656F1000B roof top controllers. Combined, they are designed for operating typical; single or multistage RTU’s and their associated local zones. For example, a typical job layout system may feature 3 RTU controllers and a total of 31 zones. This would bring to total number of nodes (individual Com addresses) to 34. -
Page 9: Terminal, Identification And Function
BACnet™ communication bus + Com + BACnet™ Com connection. BACnet™ communication bus – Com - BACnet™ Com connection. Communication bus reference terminal. DO NOT USE FOR OTHER THAN SERVICING ISSUES DO NOT WIRE SHIELD TO THIS TERMINAL 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... - Page 10 C (common) Note 4: The transformer of the unit provides power to the t Terminal Equipment Controller and the additional loads that will be wired to the Terminal Equipment Controller. 10 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 11 Fig.10 – Remote Duct Mounted Temperature Sensor S2060A1000; remote averaging duct mounted temperature sensor c/w junction box. This sensor can be used for: • Remote averaging return air temperature sensing with the sensor mounted on the return air duct. 11 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
-
Page 12: Configuring And Status Display Instructions
SYSTEM SCHEDULE OUTDOOR ALARMS STATUS MODE STATUS TEMPERATURE Monday Sys mode Outdoor 12:00 Occupied Service auto x.x °C or°F Sys mode Occupied hold Alarm Sys mode Unoccup SetClock heat Sys mode Filter cool Lost 12 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... - Page 13 Highest PI Heat Highest PI Cool Effective PI Cool Heat Demand Zone Demand Zone Demand at RTU Demand at RTU Address Address Heat Out Cool Out Heat MAC Cool MAC xxx % xxx % 13 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
-
Page 14: User Interface
Use the up or down arrow to adjust cooling setpoint Each of the sections in the menu is accessed and configured using 5 keys on the controller cover. The priority for the alarms is as follows: 14 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... - Page 15 Answering yes to this prompt will cause the all the zones attached to the RTU controller to go into occupied mode for an amount of time equal to the parameter “TOccTime” (1 to 12 hours). 15 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 16 RTU controller. Each day can be tailored to specific schedules if needed. 2 events can be configured per day. • Occupied & unoccupied periods can be set for each day. • 16 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 17 * Configuring consecutive events to the same time will cause the controller to choose the last event as the time at which it will set its schedule. In the above example, the controller will control the unoccupied set point until 7:00 AM Monday. 17 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 18 Sets Event # 4 Unoccupied time Unoccup2 Unoccup2 Unoccup2 To set To set To set Will activate unoccupied 00:00 AM 00:00 AM 00:00 AM value value value setpoints Use ▲▼ to set value, Yes key to confirm 18 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
-
Page 19: Installer Configuration Parameter Menu
• available parameters. When the desired parameter is displayed, press “Yes” to adjust it to the desired value • using “up” and “down” arrows. Once set, press “Yes” to scroll to the next parameter. 19 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... - Page 20 (fan, cooling or heating). This can be used to sequence start Default value = 10 seconds up multiple units / Terminal Equipment Controller in one location. 10 to 120 seconds 20 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 21 This parameter will select the type of operation required Sets how the Zones attached for the RTU based on the size of the system. Please refer to the RTU controller vote to to the Viconics Zoning System Guide for recommended determine the actual system settings. mode of operation.
- Page 22 Fan delay extends fan operation by 60 seconds after the Fan delay call for heating or cooling ends. Default value = Off Valid only for Auto fan mode. “On” fan mode will leave the fan always on. Off or On 22 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 23 Default value = 0.0 °F or °C Cal OS Offset that can be added/subtracted to actual displayed Outside air temperature outside air temperature ± 5.0 °F ( ± 2.5 °C ) sensor calibration Default value = 0.0 °F or °C 23 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 24 Disables heating operation based on outdoor air temperature. Outside air temperature supply heat lockout Please refer to the Viconics Zoning System Guide for recommended settings. Default value = 32 °F From –15 °F up to 120 °F (-26 °C up to 49 °C) (0 °C)
- Page 25 If network communication is lost with the zone controllers, the Return air sensor return air sensor will control the RTC to maintain this setpoint. network lost unoccupied 54 to 100°F (12°C to 37.5°C) cooling setpoint (increments: 0.5° or 5°) Default: 82°F 25 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
- Page 26 Pressure Bypass damper will maintain this supply static pressure set point. Static Pressure setpoint Please refer to the Viconics Zoning System Guide for Default: 0.8”WC recommended settings. 0 to 2 in WC (0 Pa to 500 Pa) (increments: 0.1” WC or 25 Pa)
-
Page 27: Specifications
TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION Please check with your local government for instruction on disposal of this product 27 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019... -
Page 28: Drawing & Dimensions
& D RAWING IMENSIONS Viconics Technologies Inc. 7262 Marconi Street Montreal Quebec Canada H2R 2Z5 (514) 313-8885 1 (800) 563-5660 Tel.: Toll free: sales@viconics.com I www.viconics.com 28 | 028-0324-02_LIT-VZ7656F_B-E01_EN www.viconics.com October 2019...
