Viconics VZ7656F1000W Installation Manual

Wireless rtu terminal equipment controller with modulating heat

Advertisement

Quick Links

C
ONTENTS
Typical Applications
IMPORTANT NOTICE RELATED TO PRODUCT PART NUMBERS
For the latest model and part numbers, please refer to "VT8000 and VT7000 Series Room
Controllers Catalog, version 10" (028-6100-08), which can be found on
http://www.viconics.com/.
This document contains information on active and retired products. The latter are no longer
sold by Viconics Technologies or its partners.
For additional information on 7000 Series Room Controllers and a list of replacement part
numbers, please visit http://www.viconics.com/.
Failure to follow these instructions can result in confusion or order delays.
1 |
028-0325-02_LIT-VZ7656F_W-E01_EN
VZ7656F1000W
Zigbee™ Wireless RTU Terminal Equipment
Controller with Modulating Heat
Installation Guide
For Commerci al Zoning Systems
October 2019 / 028 - 0325 - 02
NOTICE
www.viconics.com
2
3
5
6
8
9
10
12
14
19
30
31
October 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VZ7656F1000W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Viconics VZ7656F1000W

  • Page 1: Table Of Contents

    This document contains information on active and retired products. The latter are no longer sold by Viconics Technologies or its partners. For additional information on 7000 Series Room Controllers and a list of replacement part numbers, please visit http://www.viconics.com/.
  • Page 2: Safety Information

    A qualified person is one who has skills and knowledge related to the construction, installation, and operation of electrical equipment and has received safety training to recognize and avoid the hazards involved. 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 3: Before You Begin

    • Avoid touching exposed conductors and components leads with skin or clothing. For additional information about anticipated transmission delays or failures of the link, refer to NEMA ICS 1.1 (latest edition), Safety Guidelines for the Application, Installation and Maintenance of Solid State Control or its equivalent. 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 4 • Do not drop or crush the Room Controller, or allow it to come into contact with liquids. • Do not use a damaged device (such as one with a cracked screen). Failure to comply with these recommendations will result in damage to the unit and void the manufacturer’s warranty. 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 5: Installation

    Insert screws in mounting holes on each side of the base (fig. 2). Gently swing back the circuit board on the base and push on it until the tabs lock it. Strip each wire 1/4 inch from end. 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 6: Theory Of Operation

    HEORY OF PERATION The VZ7656 series uses a Viconics proprietary adaptive logic algorithm to control the space temperature. This algorithm controls the heating and or air conditioning system to minimize overshoot while still providing comfort. It provides exceptional accuracy due to its unique PI time proportioning control algorithm, which virtually eliminates temperature offset associated with traditional, differential-based on/off thermostats.
  • Page 7 Easy configuration without using any special software or additional tools. • Can be used as stand-alone or with supervision controller for monitoring purposed. • Truly scalable in terms of supported number of zones and RTU units. • 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 8: Wireless System Overview

    VERVIEW Viconics VZ7260x5x00W Zone controllers are used in conjunction with the VZ7656F1000W roof top controllers. Combined, they are designed for operating typical; single or multistage RTU’s and their associated local zones. For example, a typical job layout system may feature 3 RTU controllers and a total of 31 zones. This would bring to total number of nodes (individual Com addresses) to 34.
  • Page 9: Terminal, Identification And Function

    14 - Scom Scom Reference input for DI 1, RS, OS & DS. 15 - OS Outside air temperature sensor input. 16 - DS Discharge air temperature sensor input. 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 10 C (common) Note 4: The transformer of the unit provides power to the t Terminal Equipment Controller and the additional loads that will be wired to the Terminal Equipment Controller. 10 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 11 • Outside air temperature averaging sensing with the sensor installed in the fresh air plenum. • Supply air temperature averaging sensor for economizer models with the sensor in the mixing plenum. 11 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 12: Configuring And Status Display Instructions

    Manual scroll of each menu item is achieved by pressing the Yes (scroll) key repetitively. The last item viewed will be shown on the display for 30 seconds before returning to automatic scrolling. Temperature is automatically updated when scrolling is held. 12 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 13 Mode Status Temperature (if detected) Monday Sys Mode Occupied Outdoor Service 12:00 AM xx.x °C or °F DAS Alrm Sys Mode Unoccupied SetClock Auto Filter Sys Mode Override Comm Lost Cool Sys Mode Heat 13 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 14: User Interface

    It is possible to bring up the user menu at any time by depressing the MENU key. The status display automatically resumes after exiting the user-configuring menu. 14 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 15 System mode Schedules Clock setting Resume setting setting Override Sys mode Schedule Clock schd Y/N set Y/N set Y/N set Y/N Appears only in unoccupied mode Cancel ovrd Y/N Appears only in override mode 15 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 16 Automatic changeover mode between heating and cooling operation auto based on local zone demands voting for RTU system operation. Sys mode Cooling mode cool Cooling operation mode only Sys mode Heating mode heat Heating operation mode only 16 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 17 * Configuring consecutive events to the same time will cause the controller to choose the last event as the time at which it will set its schedule. In the above example, the controller will control the unoccupied set point until 7:00 AM Monday. 17 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 18 Sets Event # 4 Unoccupied time Unoccup2 Unoccup2 Unoccup2 To set To set To set Will activate unoccupied 00:00 AM 00:00 AM 00:00 AM value value value setpoints Use ▲▼ to set value, Yes key to confirm 18 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 19: Installer Configuration Parameter Menu

     available parameters. When the desired parameter is displayed, press “Yes” to adjust it to the desired value  using “up” and “down” arrows. Once set, press “Yes” to scroll to the next parameter. 19 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 20 This parameter (Personal Area Network Identification) is used to link specific controllers to a single specific Personal Area Network Viconics wireless gateway ( VWG / Jace-Driver ) or a Identification specific VZ76 RTU controller. For every controller reporting to a VWG / Jace-Driver or VZ76 controller, be sure you set the SAME PAN ID value.
  • Page 21 Channel 25 ID 205 Channel 25 ID 205 Channel 25 ID 205 Channel 25 ID 205 Notes: Each system with a VZ76 RTU master will use a unique PAN ID and / or Channel settings. 21 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 22 Channel 25 ID 200 Channel 25 ID 200 Notes: Each controller(s) to use same PAN ID and Channel as VWG Jace-Driver • coordinator. VWG / Jace-Driver supports network integration for required GUI / System / Status objects. 22 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 23 Channel This parameter (Channel) is used to link specific controllers to specific Viconics wireless gateway(s) (VWG Channel selection / Jace-Driver) or to the main VZ76xx RTU controller. For any system, be sure you set the SAME channel value Default value = 10 both at the network coordinator and on all the VZ72xx controller(s).
  • Page 24 This parameter will select the type of operation required Sets how the Zones attached for the RTU based on the size of the system. Please refer to the RTU controller vote to to the Viconics Zoning System Guide for recommended determine the actual system settings. mode of operation.
  • Page 25 Fan delay extends fan operation by 60 seconds after the Fan delay call for heating or cooling ends. Default value = Off Valid only for Auto fan mode. “On” fan mode will leave the fan always on. Off or On 25 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 26 Default value = 0.0 °F or °C Cal OS Offset that can be added/subtracted to actual displayed Outside air temperature outside air temperature ± 5.0 °F ( ± 2.5 °C ) sensor calibration Default value = 0.0 °F or °C 26 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 27 Disables heating operation based on outdoor air temperature. Outside air temperature supply heat lockout Please refer to the Viconics Zoning System Guide for recommended settings. Default value = 32 °F (0 °C) From –15 °F up to 120 °F (-26 °C up to 49 °C) (increments: 5°...
  • Page 28 If network communication is lost with the zone controllers, the Return air sensor return air sensor will control the RTC to maintain this setpoint. network lost unoccupied 54 to 100°F (12°C to 37.5°C) cooling setpoint (increments: 0.5° or 5°) Default: 82°F 28 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 29 Pressure Bypass damper will maintain this supply static pressure set point. Static Pressure setpoint Please refer to the Viconics Zoning System Guide for Default: 0.8”WC recommended settings. 0 to 2 in WC (0 Pa to 500 Pa) (increments: 0.1” WC or 25 Pa)
  • Page 30: Specifications

    TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Please check with your local government for instruction on disposal of this product 30 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
  • Page 31: Drawing & Dimensions

    & D RAWING IMENSIONS Viconics Technologies Inc. 7262 Marconi Street Montreal Quebec Canada H2R 2Z5 (514) 313-8885 1 (800) 563-5660 Tel.: Toll free: sales@viconics.com I www.viconics.com 31 | 028-0325-02_LIT-VZ7656F_W-E01_EN www.viconics.com October 2019...
