Vehicle connections

The connection information listed below is specific to the 2017 Toyota Camry (H Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low
H1/2 Tan/Black (Data) HS CAN High
H1/3 Orange/Brown (Data) HS CAN Low
H1/4 Orange/Green (Data) HS CAN High
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black (Data) RDA
H1/8 Yellow/Black (Data) SIL Data
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black
(-) Pk Light Output
H2/2 Blue/White No Connection
H2/3 Dk. Green/Black No Connection
H2/4 Red/White (-) Trunk Output
H2/5 Brown/Black No Connection
H2/6 Brown/White No Connection
H2/7 White (+) No Connection
H2/8 Violet/Black No Connection
H2/9 Dk. Blue/Black No Connection
H2/10 Lt. Blue/Black No Connection
H2/11 Brown/Red
(+) Siren Output
H2/12 Pink No Connection
H2/13 Violet No Connection
H2/14 Brown No Connection
H2/15 White/Blue No Connection
H2/16 Red/Blue No Connection
H2/17 Black/White No Connection
H2/18 Orange/Black No Connection
H2/19 Blue No Connection
H2/20 Green No Connection
H2/21 Gray
(-) Hood Switch Input
10 933.TL10 2.29.195.3 2017 Toyota Camry (H Key)
©2022 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
OBD-Data Link Connector, white 16 pin plug, pin 14
OBD-Data Link Connector, white 16 pin plug, pin 6
No Connection
No Connection
No Connection
No Connection
Body ECU on dash fuse box, white 30 pin plug, pin 16
OBD-Data Link Connector, white 16 pin plug, pin 7
Connects To
Wire Location
[5] Headlight Switch, black 20 pin plug, pin 18
Parking lights connection required when not available through Data
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
[2]
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
[1]
(+/-) Wire Color Connection
Data White Mandatory
Data Blue Mandatory
Data Blue Mandatory
Data Gray Remote Start
Only
(+/-) Wire Color Connection
- Black Optional
Security Only
