SmartRunner 3-D ToF
Product Specifications
2.3

Dimension Drawing

The sensor housing has the following dimensions.
Figure 2.7
All dimensions in mm.
Note
Further technical data can be found on the datasheet for the sensor. You will find the datasheets
on our website.
12
PEPPERL+FUCHS
GOOD
BAD
LINK/ACT
SPEED
OUT1
OUT2
BUS
PWR
56
Dimension Drawing
60
2
59
165
15
