SmartRunner 3-D ToF
Installation
Opening Angle
The opening angle of the 3-D measuring range on the vertical axis is 35°.
x
Figure 3.2
The opening angle of the 3-D measuring range on the horizontal axis is 47°.
x
Figure 3.3
y
Vertical axis - VTE7500-F400-B12-A1500
y
Horizontal axis - VTE7500-F400-B12-A1500
35°
47°
z
z
17
