- Page 1 FACTORY AUTOMATION HANDBUCH / MANUAL / MANUEL / MANUALE TopScan-S Certification...
- Page 2 Inhalt / Content / Sommaire / Indice Deutsch ............3 English .
-
Page 3: Table Of Contents
Components of TopScan-S ........ -
Page 4: Design Of The Device
Active Infrared Scanner TopScan-S Design of the Device Design of the Device Figure 1.1 Internal design of the device Removable housing cover Aluminum profile Module holder Handle to set the detection angle Figure 1.2 Design of the master module (chassis lever) -
Page 5: Functional Description
Functional Description The TopScan-S is an active infrared triangulation scanner. The TopScan-S has been designed for sensing while mounted on a swinging door panel. The intended use of TopScan-S is to make safe automatic swinging doors in com- plying with German standard DIN 18650. If used as intended, the sensor shall... -
Page 6: 3.1.2 Installation Of The Module
The connection cable to the door control er can be passed through the end cap by means of a cable bushing. The optional section seal (o) can be used to seal the TopScan-S section to conform with IP54. Setting the Monitoring Beam - Leading Edge Designate either the transmitting light beam or receiving light beam as vertical to optimize coverage of the door's leading edge. -
Page 7: Optical Setting Of The Sensor
Active Infrared Scanner TopScan-S Installation and Initial Operation Optical Setting of the Sensor You can swivel the sensing field away from the door or towards the door by setting the detection an- gle. The detection angle can be adjusted from 0° to + 25°. -
Page 8: Sensing Field
Active Infrared Scanner TopScan-S Sensing Field Detection Angle of the Sensor: Lay the test card on the ground with its mark parallel to the door. Place the test specimen on the door-side of the test card mark. (see Figure 3.7). -
Page 9: Master / Slave Operation
Active Infrared Scanner TopScan-S Master / Slave Operation Master / Slave Operation Difference between Master and Slave Modules It is possible to add up to seven additional slave modules together with one master module. The differences between the master module and the slave module are as follows: Master module: with relay;... -
Page 10: Test
Pulse Diagram of Time Sequence If the TopScan-S is used as a safety device, the device has to be tested cyclically by the door control- ler. This test should be conducted only if no object is detected, and the recommended door position for the test is completely open. -
Page 11: Troubleshooting
Active Infrared Scanner TopScan-S Troubleshooting Troubleshooting Error Cause Remedy The sensor does not initial- Supply voltage is not correct. Check the voltage supply. ize or react. • The sensor is disturbed by the movement of the door. • Change the sensor's detection •... -
Page 12: Wiring Diagram
• Test input is inactive when signal is -3 V DC to +5 V DC or disconnected • Test input is active when signal is +11 V DC to +30 V DC Components of TopScan-S Part Numbers Description 208177 AIR 17-S MASTER 208178 AIR 17-S SLAVE Table 10.1 Components of TopScan-S... -
Page 13: Disposal, Repair, Maintenance
Active Infrared Scanner TopScan-S Disposal, Repair, Maintenance Disposal, Repair, Maintenance 11.1 Disposal Dispose of the device according to the applicable national laws and regulations. For example, take the sensor to an electronic waste collection center. 11.2 Repair Device may be repaired by the manufacturer only. - Page 14 Active Infrared Scanner TopScan-S Disposal, Repair, Maintenance...
- Page 15 With regard to the supply of products, the current issue of the following document is applicable: The General Terms of Delivery for Products and Services of the Electrical Industry, published by the Central Association of the Electrical Industry (Zentralverband Elektrotechnik und Elektroindustrie (ZVEI) e.V.) in its most recent version as well as the supplementary clause: "Expanded reservation of proprietorship"...
- Page 16 Twinsburg, Ohio 44087 · USA Tel. +1 330 4253555 E-mail: sales@us.pepperl-fuchs.com Asia Pacific Headquarters Pepperl+Fuchs Pte Ltd. Company Registration No. 199003130E Singapore 139942 Tel. +65 67799091 E-mail: sales@sg.pepperl-fuchs.com www.pepperl-fuchs.com DOCT-1199B 194964 Subject to modifications Copyright PEPPERL+FUCHS • Printed in Germany 05/2008...
