- Page 1 USER MANUAL PCIe/104 (PCI/104-Express) to PCI Express Adapter Bottom Stacking Model CTIM-00056 (0.00) - November 24, 2011 Arrow.com. Downloaded from...
-
Page 2: Table Of Contents
Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual Table of Contents Table of Contents ..............................2 Copyright Notice ..............................3 Trademark Acknowledgement ..........................3 Revision History..............................3 Introduction ................................. 4 Features ................................4 1. Block Diagram ............................... 4 2. -
Page 3: Copyright Notice
Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual Copyright Notice The information contained in this document is subject to change without notice. Connect Tech Inc. shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance, or use of this material. -
Page 4: Introduction
Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual Introduction Connect Tech's PCI/104-Express to PCI Express Adapter enables users to install any x1, x4, x8 or x16 lane PCI Express card in a PCI/104-Express stack. -
Page 5: Detailed Hardware Description
Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual 2. Detailed Hardware Description An ADG021 is depicted below with all of the user accessible locations defined. Further detailed descriptions of these locations will be defined below. -
Page 6: Hardware Installation
Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual Auxiliary Signals Jumper Block Position A: Should only be installed when you SBC power supply does not supply +3.3V to the PCI/104-Express bus. Position B: In some cases PCI/104-Express SBC require the PEG_ENA signal to be enabled to use the x16 lane bus, if your SBC requires this please install this jumper. -
Page 7: Pinouts And Signal Interconnect
Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual 3. Pinouts and Signal Interconnect Below is a listing of all signal interconnect between the PCI Express connector and the PCI/104-Express connector. Power, ground and presence detection signals have been removed from this list. - Page 8 Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual Side B JTAG2 no connection Side B JTAG3 no connection Side B JTAG4 no connection Side B JTAG5 no connection Side B PERST# PE_RST# Side B...
-
Page 9: Pci/104-Express Sbc Compatibility
DOWN ONLY configuration, or a stack UP ONLY configuration. In these cases you must use the correct stacking Connect Tech adapter. Below is a compatibility list of all the known PCIe/104 or PCI- 104/Express CPU boards that are on the market at the time this document was created. -
Page 10: Power Notes
Connect Tech PCIe/104 to PCI Express Adapter - Bottom Stacking Model - User Manual 5. Power Notes Some PCI/104-Express SBC systems will not come with +3.3V power over the PCI/104-Express connector. If this is the case, enable jumper block J1 Position A** (See errata) to enable the on board regulator to generate +3.3V (which is limited to 1.5A) for your PCI Express card. -
Page 11: Limited Lifetime Warranty
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc. must be pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number marked on the outside of the package and sent prepaid, insured and packaged for safe shipment.
