- Page 1 USER MANUAL PCIe/104 (PCI/104-Express) to PCI Express Adapter Top Stacking Model CTIM-00054 (0.01) - March 26, 2010...
-
Page 2: Table Of Contents
PCI-104/Express to PCI Express Adapter User Manual Table of Contents Table of Contents ..............................2 Copyright Notice ..............................3 Trademark Acknowledgement ..........................3 Revision History..............................3 Introduction ................................. 4 Features ................................4 1. Block Diagram ............................... 4 2. Hardware Installation ............................. 5 3. -
Page 3: Copyright Notice
PCI/104-Express to PCI Express Adapter Copyright Notice The information contained in this document is subject to change without notice. Connect Tech Inc. shall not be liable for errors contained herein or for incidental consequential damages in connection with the furnishing, performance, or use of this material. -
Page 4: Introduction
PCI/104-Express to PCI Express Adapter Introduction Connect Tech's PCI/104-Express to PCI Express Adapter enables users to install any x1, x4, x8 or x16 lane PCI Express card in a PCI/104-Express stack. This convenient adapter board enables the testing and development for standard PCI Express cards in the PCI/104-Express environment. -
Page 5: Hardware Installation
PCI/104-Express to PCI Express Adapter 2. Hardware Installation PC104 Stand-Offs When installing the ADG017 or ADG20 device into your PCI/104-Express SBC system, four proper stack heights (0.6”) PC/104 standoffs must be used. If standoffs are not used, there is high likelihood that the PCI/104-Express connector can be damaged. -
Page 6: Pinouts And Signal Interconnect
PCI/104-Express to PCI Express Adapter 3. Pinouts and Signal Interconnect Below is a listing of all signal interconnect between the PCI Express connector and the PCI/104-Express connector. Power, ground and presence detection signals have been removed from this list. Any other PCI/104-Express signals not listed, are no connects. - Page 7 PCI/104-Express to PCI Express Adapter Side B JTAG2 no connection Side B JTAG3 no connection Side B JTAG4 no connection Side B JTAG5 no connection Side B PERST# PE_RST# Side B REFCLK+ 36 OR 48 PEx1_0Clkp OR PEx16_x8_x4_Clkp Side B REFCLK- 38 OR 50 PEx1_0Clkn OR PEx16_x8_x4_Clkn...
-
Page 8: Pci/104-Express Sbc Compatibility
In this case the Connect Tech adapter cannot be used. Below is a compatibility list of all PCI/104-Express CPU boards that are on the market at the time this document was created. -
Page 9: Power Notes
PCI/104-Express to PCI Express Adapter 5. Power Notes Some PCI/104-Express SBC systems will not come with +3.3V power over the PCI/104-Express connector. If this is the case, enable jumper block J1 Position A** (See errata) to enable the on board regulator to generate +3.3V (which is limited to 1.5A) for your PCI Express card. -
Page 10: Limited Lifetime Warranty
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc. business partner or to Connect Tech Inc. along with proof of purchase. Product returned to Connect Tech Inc. must be pre-authorized by Connect Tech Inc. with an RMA (Return Material Authorization) number marked on the outside of the package and sent prepaid, insured and packaged for safe shipment.
