D M X T R A I T S
CHANNEL
6 CH 7 CH 8 CH 13 CH
1 1 1
2 2 2
3 3 3
4 4 4
5 5 5
6 6 6
7 7
8
DMX VALUES FUNCTION
1 000 - 255
2 000 - 255
3 000 - 255
4 000 - 255
5 000 - 255
6 000 - 255
7 000 - 255
000 - 031
032 - 063
064 - 095
8 096 - 127
128 - 159
160 - 191
192 - 223
224 - 255
9 000 - 255
000 - 019
020 - 039
040 - 059
060 - 079
080 - 099
100 - 119
10
120 - 139
140 - 159
160 - 179
180 - 199
200 - 219
220 - 239
240 - 255
11 000 - 255
12 000 - 255
CONTINUED ON NEXT PAGE
Red, 0% to 100%
Green, 0% to 100%
Blue, 0% to 100%
White, 0% to 100%
Amber, 0% to 100%
UV, 0% to 100%
Master Dimmer, 0% to 100%
Strobe
LED Off
LED On
Strobe, slow to fast
LED On
Strobe Pulse, slow to fast
LED On
Random Strobe
LED On
Color Macro, see Color Macro Chart section of
this manual
Auto Programs
No Function
Program 1
Program 2
Program 3
Program 4
Program 5
Program 6
Program 7
Program 8
Program 9
Program 10
Program 11
Program 12
Auto Program Speed, slow to fast
Auto Program Fade, slow to fast
