Section 3 - Installation
79.5" (201.9cm)
51.0" (129.6cm)

Figure 3-2. System Dimensions (4500SL)

120.0" (304.8cm)
79.5" (201.9cm)
Wall
49.1" (126.2)
19.8 (50.3cm)
"
19.8" (50.3cm)

Figure 3-3. System Dimensions (4500W)

3-3
